Generating Partition Function – sp_tblCreatePartitionFunction available don GitHub

If you are working with large databases you have come to situation when you need to partition the large tables.

To be able to partition a table, you need to create a Partition Function. Creation of Partition Function is quite easy, however if you need to create a larger number of partitions at initial phase, it can be pretty annoying as you have to define all the ranges for each partition. Also it is easy to make a type in the list of boundary values and as a result create a partition function with wrong partition alignment.

To simplify that process I’m presenting here a stored procedure which takes care about that and generates the partition function automatically based on input parameters

sp_tblCreatePartitionFunction

As mentioned above, the sp_tblCreatePartitionFunction takes care about generation of the partition function based on input parameters.

You can find complete source code in my SQL-Scripts project on GitHub under the TablesManagement\Partitioning folder.

The stored procedure provides support for generation of ranges based on smallint, int, bigint, date, datetime and datetime2 data types.

Stored procedure generates a partition function with boundary values between @rangeStart and @rangeEnd parameters.

The stored procedure is marked as system stored procedure in the script so it means that it can operate in the context of the current user database.

Parameters

The input parameters define the ranges and the way how the partition function is generated

The available input parameters for the function are @pfName, @rangeStart, @rangeEnd, @boundaryType, @incrementValue, @incrementUnit, @useIntegerDates, @integerFormatType and @printScriptOnly

@pfName

Defines the partition function Name. the parameter data type is nvarchar(128) which corresponds to sysname.

@rangeStart

Defines the starting range for generation of the partition function. The parameter is sql_variant. You have to pass parameter of supported data type for the range. As mentioned above the supported data types are smallint, int, bigint, date, datetime and datetime2.

To simplify specification of the range, you can pass the parameter as string. If the value passed as string represents a DateTime it is automatically converted to datetime data type.

You can also pass a value with a data type specifier. The data type specifier must be first character of the string and the value must follow. The supported data type specifiers are 'D' - date, 'T' - datetime, 'B' - bigint, 'I' - int and 'S' - smallint.

Below are some examples of supported strings passed as @rangeStart :

Sample value Result
'2016-01-01' Converted to datetime 2016-01-01
20160101 Converted to datetime 2016-01-01
D2016-01-01 Converted to date 2016-01-01
T20160101 Converted to datetime 2016-01-01
B1010 Converted to bigint 100
I1010 Converted to int 100
S1010 Converted to smallint 100

The @rangeStart representing a date can be altered during the partition function generation based on the @incrementUnit parameter. The @rangeStart is shifted to the beginning of corresponding unit.. See the @incrementUnit parameter for details.

The @rangeStart is included in the generated ranges.

@rangeEnd

Represents then end of range which should be generated for the partition function. The supported data types are the same as for the @rangeStart. See the @rangeStart for details.

The @rangeEnd is inclusive in the range, but may not be included in the final generated partition function in dependency on the @incrementValue and @incrementUnit parameters. See those parameters for details.

@boundaryType

Specifies the boundary type of the boundary values for the partition function. It can be either LEFT or RIGHT. It defines whether the boundary value is included in the left or right partition respective to the boundary value. Default value is RIGHT.

@incrementValue

Defines increment of the boundary values. This means that the @rangeStart value is incremented by the @incrementValue until @rangeEnd is reached.

@incrementUnit

Specifies the unit of the increment. It is being used only for range values representing date. The allowed units are YEAR, MONTH, WEEK, ISO_WEEK, DAY.

In each iteration step the @rangeStart value is incremented by the @incrementValue number of @incrementUnit.

Also the @incrementUnit may have impact on the @rangeStart value. If the @rangeStart value does not point to the first day of respective unit, it is being automatically shifted to the beginning of corresponding unit based on the @rangeStart value.

Samples of @rangeStart shifting:

@rangeStart @incrementUnit @rangeStart shifted to
'2016-03-17' YEAR '2016-01-01'
'2016-03-17' MONTH '2016-03-01'
'2016-03-17' WEEK '2016-03-14'
'2016-01-01' ISO_WEEK '2015-12-28'

@useIntegerDates

Specifies whether boundary values representing dates in the partition function should be represented as int date types or corresponding date, datetime or datetime2 data type. In case of  @useIntegerDates = 0 the boundary value is always first day of corresponding @incrementUnit.

In case of @useIntegerDates = 1 the boundary value is expressed as integer number and the value representing the range depends on the @integerFormatType parameter. See the @integerFormatType for details

It is being used only for date ranges. Default value is 1.

@integerFormatType

Specifies integer format of date range value. When the partition function is being generated and date ranges are being used, the range value is internally always represented by a first day of corresponding rage. if the @useIntegerDate = 1 the final boundary value is generated based on the format type.

Supported format types are:

FormatType Boundary value formatting
1 yyyyMMdd For example 20160101
2 yyyyxx(x) where xxx(x) correspond to appropriate month, week or day within particular year. For example 2016053 represents a day 53 of year 2016. 201643 represents week or iso_week 43 in year 2016

Default value is 2.

@printScriptOnly

Specifies whether only the partition function CREATE script is being printed or the partition function is being automatically crated.

The default value is 1, this means that only script is printed.

Samples

Below are some sample usages of the stored procedure.

Sample 1

sp_tblCreatePartitionFunction
    @pfName = 'myPf'
   ,@rangeStart = 1
   ,@rangeEnd = 1001
   ,@boundaryType = 'RIGHT'
   ,@incrementvalue = 100
CREATE PARTITION FUNCTION [myPf](int) AS RANGE RIGHT FOR VALUES (
    1
   ,101
   ,201
   ,301
   ,401
   ,501
   ,601
   ,701
   ,801
   ,901
   ,1001
)

Sample 2

sp_tblCreatePartitionFunction
    @pfName = 'myPf'
   ,@rangeStart = '2016-01-01'
   ,@rangeEnd = '2020-12-31'
   ,@boundaryType = 'RIGHT'
   ,@incrementvalue = 1
   ,@incrementUnit = 'YEAR'
   ,@useIntegerDates = 1
   ,@integerFormatType = 2

CREATE PARTITION FUNCTION [myPf](int) AS RANGE RIGHT FOR VALUES (
    2016
   ,2017
   ,2018
   ,2019
   ,2020
)

Sample 3

sp_tblCreatePartitionFunction
    @pfName = 'myPf'
   ,@rangeStart = '2016-01-01'
   ,@rangeEnd = '2016-12-31'
   ,@boundaryType = 'LEFT'
   ,@incrementvalue = 1
   ,@incrementUnit = 'MONTH'
   ,@useIntegerDates = 1
   ,@integerFormatType = 2
CREATE PARTITION FUNCTION [myPf](int) AS RANGE LEFT FOR VALUES (
    20160101
   ,20160201
   ,20160301
   ,20160401
   ,20160501
   ,20160601
   ,20160701
   ,20160801
   ,20160901
   ,20161001
   ,20161101
   ,20161201
)

Sample 4

sp_tblCreatePartitionFunction
    @pfName = 'myPf'
   ,@rangeStart = '2016-01-01'
   ,@rangeEnd = '2016-12-31'
   ,@boundaryType = 'LEFT'
   ,@incrementvalue = 1
   ,@incrementUnit = 'MONTH'
   ,@useIntegerDates = 0
CREATE PARTITION FUNCTION [myPf](datetime) AS RANGE LEFT FOR VALUES (
    '20160101'
   ,'20160201'
   ,'20160301'
   ,'20160401'
   ,'20160501'
   ,'20160601'
   ,'20160701'
   ,'20160801'
   ,'20160901'
   ,'20161001'
   ,'20161101'
   ,'20161201'
)
Advertisement

SQL Server is wasting space when altering fixed length column

Recently I was going through the archives of posts by Kalen Delaney blog and I came across very interesting post Did you know? — Altering the length of a fixed-length column.  This article gives information how SQL Server is wasting space when you alter a fixed length column and increase its length.

It is interesting so I wanted to take a closer look on this and take a look on the physical db pages to see what happens and to see how the data are stored after alter is done.

Test data preparation and initial view of the data

So first let’s prepare a testing table with some testing data.

CREATE TABLE dbo.AlterTest (
    ID int NOT NULL IDENTITY(1,1),
    col1 char(2000),
    col2 char(1000),
    col3 int
)
GO
INSERT INTO dbo.AlterTest (col1, col2, col3)
VALUES('aaa', 'bbb', ABS(BINARY_CHECKSUM(NEWID())))
GO 4

Now if we take a look on the columns information in metadata tables using Kalen’s query to sys.system_internal_partition_columns we can see the offsets of the table columns.

SELECT
    c.name AS column_name,
    column_id,
    max_inrow_length,
    pc.system_type_id,
    leaf_offset
FROM sys.system_internals_partition_columns pc
INNER JOIN sys.partitions p ON p.partition_id = pc.partition_id
INNER JOIN sys.columns c ON column_id = partition_column_id AND c.object_id = p.object_id
WHERE p.object_id=object_id('AlterTest');
column_name   column_id   max_inrow_length system_type_id leaf_offset
------------- ----------- ---------------- -------------- -----------
ID            1           4                56             4
col1          2           2000             175            8
col2          3           1000             175            2008
col3          4           4                56             3008

As we can see, the physical order is the order in which the columns were defined using the CREATE TABLE statement.

Once we have the data in the table, let’s take a look on how the data are stored. The below query will work only on SQL Server 2008+ and is using undocumented virtual column %%physloc%% which provides information about rows physical location in database and undocumented function sys.fn_PhysLocCracker, which cracks the physical location to human readable FileID, PageID and SlotID.

SELECT
    DB_ID() AS DBID
    ,pl.*
    ,t.*
FROM dbo.AlterTest t
CROSS APPLY sys.fn_PhysLocCracker(%%physloc%%) pl
DBID   file_id     page_id     slot_id     ID          col1    col2    col3
------ ----------- ----------- ----------- ----------- ------- ------ -----------
16     1           168         0           1           aaa     bbb    587800818
16     1           168         1           2           aaa     bbb    1396332306
16     1           171         0           3           aaa     bbb    844570652
16     1           171         1           4           aaa     bbb    1332601405

Let’s take a look on the first physical page 168.

dbcc traceon (3604,-1)
GO
dbcc page(16,1,168,3)
GO

The partial results are below

PAGE: (1:168)

BUFFER:

BUF @0x00000005011003C0

bpage = 0x000000048C308000          bhash = 0x0000000000000000          bpageno = (1:168)
bdbid = 16                          breferences = 0                     bcputicks = 0
bsampleCount = 0                    bUse1 = 44191                       bstat = 0xb
blog = 0xab21cccc                   bnext = 0x0000000000000000

PAGE HEADER:

Page @0x000000048C308000

m_pageId = (1:168)                  m_headerVersion = 1                 m_type = 1
m_typeFlagBits = 0x0                m_level = 0                         m_flagBits = 0x8000
m_objId (AllocUnitId.idObj) = 98    m_indexId (AllocUnitId.idInd) = 256
Metadata: AllocUnitId = 72057594044350464
Metadata: PartitionId = 72057594039959552                                Metadata: IndexId = 0
Metadata: ObjectId = 549576996      m_prevPage = (0:0)                  m_nextPage = (0:0)
pminlen = 3012                      m_slotCnt = 2                       m_freeCnt = 2062
m_freeData = 6126                   m_reservedCnt = 0                   m_lsn = (37:227:3)
m_xactReserved = 0                  m_xdesId = (0:0)                    m_ghostRecCnt = 0
m_tornBits = 0                      DB Frag ID = 1

Allocation Status

GAM (1:2) = ALLOCATED               SGAM (1:3) = ALLOCATED
PFS (1:1) = 0x62 MIXED_EXT ALLOCATED  80_PCT_FULL                        DIFF (1:6) = CHANGED
ML (1:7) = NOT MIN_LOGGED

Slot 0 Offset 0x60 Length 3015

Record Type = PRIMARY_RECORD        Record Attributes =  NULL_BITMAP    Record Size = 3015

Memory Dump @0x000000002054A060

0000000000000000:   1000c40b 01000000 61616120 20202020 20202020  ..Ä.....aaa
0000000000000014:   20202020 20202020 20202020 20202020 20202020
0000000000000028:   20202020 20202020 20202020 20202020 20202020
...
...
00000000000007BC:   20202020 20202020 20202020 20202020 20202020
00000000000007D0:   20202020 20202020 62626220 20202020 20202020          bbb
00000000000007E4:   20202020 20202020 20202020 20202020 20202020
...
...
0000000000000BA4:   20202020 20202020 20202020 20202020 20202020
0000000000000BB8:   20202020 20202020 f2200923 040000                     ò     #...

Slot 0 Column 1 Offset 0x4 Length 4 Length (physical) 4

ID = 1

Slot 0 Column 2 Offset 0x8 Length 2000 Length (physical) 2000

col1 = aaa

Slot 0 Column 3 Offset 0x7d8 Length 1000 Length (physical) 1000

col2 = bbb

Slot 0 Column 4 Offset 0xbc0 Length 4 Length (physical) 4

col3 = 587800818

Slot 1 Offset 0xc27 Length 3015

We can see, that the physical storage corresponds to the metadata stored in the system table sys.system_internal_partition_columns.

Altering the column length and analyzing impacts

Now let’s alter the table and increase the length of Col1 to 3000 characters and take a look what happens.

ALTER TABLE dbo.AlterTest
    ALTER COLUMN Col1 char(3000)
GO

If we take a look on the sys.system_iternal_partition_columns we will see following:

column_name   column_id   max_inrow_length system_type_id leaf_offset
------------- ----------- ---------------- -------------- -----------
ID            1           4                56             4
col2          3           1000             175            2008
col3          4           4                56             3008
col1          2           3000             175            3012

We can see, that the offset of the Col1 has changed and the Column was moved to the end of the record. From here we can see, that the original 2000 bytes were wasted. If we take a look on the physical page 168 as above, we will see, that there is no change in the physical page as the this change to the column is metadata change only.

Impact on new records

So let’s take a look what impact this have on new records added to the table.

INSERT INTO dbo.AlterTest (col1, col2, col3)
VALUES('ccc', 'ddd', ABS(BINARY_CHECKSUM(NEWID())))
GO 4
SELECT
    DB_ID() AS DBID
    ,pl.*
    ,t.*
FROM dbo.AlterTest t
CROSS APPLY sys.fn_PhysLocCracker(%%physloc%%) pl
DBID   file_id     page_id     slot_id     ID          col1   col2  col3
------ ----------- ----------- ----------- ----------- ------ ----- -----------
16     1           168         0           1           aaa    bbb   587800818
16     1           168         1           2           aaa    bbb   1396332306
16     1           171         0           3           aaa    bbb   844570652
16     1           171         1           4           aaa    bbb   1332601405
16     1           175         0           5           ccc    ddd   2059368981
16     1           177         0           6           ccc    ddd   1449062892
16     1           178         0           7           ccc    ddd   267569086
16     1           179         0           8           ccc    ddd   1325350591

From the results we can see, that the first 4 records originally inserted are occupied only two pages as two records were stored per database page. After the update we can see that each single record is occupied its own page. This is due to the fact that the record length has increased not only by the 1000 characters by which the length of the Col1 was modified but also the original 2000 bytes were wasted. there fore the data length on the page increased from 3008 bytes to 6008 bytes.

Now let’s take a closer look on the physical page. For example the first page occupied by the newly inserted data  (page 175).

dbcc page(16,1,175,3)
GO

Partial results of the DBCC command are here:

PAGE: (1:175)

BUFFER:

BUF @0x0000000503366540

bpage = 0x00000004D7F84000          bhash = 0x000000067753ED81          bpageno = (1:175)
bdbid = 16                          breferences = 0                     bcputicks = 0
bsampleCount = 0                    bUse1 = 45327                       bstat = 0x10b
blog = 0x212121cc                   bnext = 0x0000000000000000

PAGE HEADER:

Page @0x00000004D7F84000

m_pageId = (1:175)                  m_headerVersion = 1                 m_type = 1
m_typeFlagBits = 0x0                m_level = 0                         m_flagBits = 0x8000
m_objId (AllocUnitId.idObj) = 98    m_indexId (AllocUnitId.idInd) = 256
Metadata: AllocUnitId = 72057594044350464
Metadata: PartitionId = 72057594039959552                                Metadata: IndexId = 0
Metadata: ObjectId = 549576996      m_prevPage = (0:0)                  m_nextPage = (0:0)
pminlen = 6012                      m_slotCnt = 1                       m_freeCnt = 2079
m_freeData = 6111                   m_reservedCnt = 0                   m_lsn = (37:390:11)
m_xactReserved = 0                  m_xdesId = (0:0)                    m_ghostRecCnt = 0
m_tornBits = 0                      DB Frag ID = 1

Allocation Status

GAM (1:2) = ALLOCATED               SGAM (1:3) = NOT ALLOCATED
PFS (1:1) = 0x62 MIXED_EXT ALLOCATED  80_PCT_FULL                        DIFF (1:6) = CHANGED
ML (1:7) = NOT MIN_LOGGED

Slot 0 Offset 0x60 Length 6015

Record Type = PRIMARY_RECORD        Record Attributes =  NULL_BITMAP    Record Size = 6015

Memory Dump @0x000000002267A060

0000000000000000:   10007c17 05000000 df5af8d7 04000000 ffffffff  ..|.....ßZø×....ÿÿÿÿ
0000000000000014:   ffffff7f 9860f8d7 04000000 0040f8d7 04000000  ÿÿÿ..`ø×.....@ø×....
0000000000000028:   01000000 00000000 63000000 00000000 dd7618f4  ........c.......Ýv.ô
0000000000000794:   00000000 00000000 00000000 00000000 01000000  ....................
00000000000007A8:   000071d8 fe070000 c072210e 00000000 00000000  ..qØþ...Àr!.........
00000000000007BC:   00000000 00000000 00000000 00000000 00000000  ....................
00000000000007D0:   00000000 00000000 64646420 20202020 20202020  ........ddd
00000000000007E4:   20202020 20202020 20202020 20202020 20202020
0000000000000BA4:   20202020 20202020 20202020 20202020 20202020
0000000000000BB8:   20202020 20202020 157abf7a 63636320 20202020          .z¿zccc
0000000000000BCC:   20202020 20202020 20202020 20202020 20202020
0000000000000BE0:   20202020 20202020 20202020 20202020 20202020
000000000000175C:   20202020 20202020 20202020 20202020 20202020
0000000000001770:   20202020 20202020 20202020 050000                         ...

Slot 0 Column 1 Offset 0x4 Length 4 Length (physical) 4

ID = 5

Slot 0 Column 67108865 Offset 0x8 Length 0 Length (physical) 2000

DROPPED = NULL

Slot 0 Column 3 Offset 0x7d8 Length 1000 Length (physical) 1000

col2 = ddd

Slot 0 Column 4 Offset 0xbc0 Length 4 Length (physical) 4

col3 = 2059368981

Slot 0 Column 2 Offset 0xbc4 Length 3000 Length (physical) 3000

col1 = ccc

From the output above we can see, the now on the physical page, there is a Column 67108865 (DROPPED) following the Column1 and Column2 has physically moved to the end of the record at offset 0xbc4 (3012).  Also from the page dump we can see that the space from the offset 0x8 to 0x7d7 is containing a mess and that those 2000 bytes are wasted.

As we can see, the original query to sys.system_internals_partition_columns doesn’t show the Column with ID 67108865 (DROPPED). It’s because it uses join to the sys.columns and the DROPPED column is not part of the table, but is par tof the partition. If we use the query without join to the sys.columns it will be shown also in the query output.

SELECT
    partition_column_id,
    max_inrow_length,
    pc.system_type_id,
    leaf_offset,
    is_dropped
FROM sys.system_internals_partition_columns pc
INNER JOIN sys.partitions p ON p.partition_id = pc.partition_id
WHERE p.object_id=object_id('AlterTest');
partition_column_id max_inrow_length system_type_id leaf_offset is_dropped
------------------- ---------------- -------------- ----------- ---------
1                   4                56             4           0
67108865            2000             175            8           1
3                   1000             175            2008        0
4                   4                56             3008        0
2                   3000             175            3012        0

It Seems that the dropped columns have IDs starting from 67108865 and the numbers increase as there are more dropped columns. Also the DROPPED columns have flag is_dropped = 1.

Multiple updates of the column size

In previous examples we took a look on the update to a single column and in Delaney’s post you can see the result if we want to update multiple column. In case we try to multiple columns, space allocated for all the original columns is dropped and new space allocated. But what happens if we update the same column multiple times? Let’s make a simple test.

CREATE TABLE AlterTest2 (
    id int not null identity(1,1),
    Col1 char(1000),
    Col2 char(1000),
    Col3 int
)
GO
ALTER TABLE AlterTest2
ALTER COLUMN Col1 char(2000)
GO
ALTER TABLE AlterTest2
ALTER COLUMN Col1 char(2500)
GO
SELECT
    partition_column_id,
    max_inrow_length,
    pc.system_type_id,
    leaf_offset,
    is_dropped
FROM sys.system_internals_partition_columns pc
INNER JOIN sys.partitions p ON p.partition_id = pc.partition_id
WHERE p.object_id=object_id('AlterTest2');
partition_column_id max_inrow_length system_type_id leaf_offset is_dropped
------------------- ---------------- -------------- ----------- ----------
1                   4                56             4           0
67108865            1000             175            8           1
3                   1000             175            1008        0
4                   4                56             2008        0
67108866            2000             175            2012        1
2                   2500             175            4012        0

From the example we can see, that each change which increase the fixed column length causes that the original column space is dropped and additional space is allocated.

Recovering the wasted space

It is great, that extending the column width of fixed length column is a metadata only operation as it is very quick and avoids blocking especially on large tables, but on the other side as we can see, this can cause a significant space wasting.

In case there will be less new inserts into the table than the current about of rows we do not need to take care about the wasted space much (from the point of wasted storage space) as the metadata change didn’t affect the current records and on the current records we are saving the space as we have extended the record length and only the new records inserted are wasting the space.

On the other side, if we know there will be a lot of inserts and reads of the newly inserted records, than it’s a good idea to recover the wasted space as the data will consume more space and further reads will have to read more unnecessary data.

In the comments to the original post there are some suggestions how to resolve the problem.

From my perspective if the table is already clustered, we do not need to crop and recreate the clustered index, but it is enough to REBUILD the index. The rebuild operation will reorder the data and free up the wasted space and also write the original data with new record length.

In the case of heap, creating and dropping clustered index will be quite costly operation which will move the data twice. On small tables this doesn’t matter but on larger amounts of data it will be better to do simple SELECT * INTO newTable from aTable and than simply drop the original table and rename the new one to the original one.

SELECT
*
INTO dbo.AlterTest2
FROM dbo.AlterTest
GO
SELECT
    DB_ID() AS DBID
    ,pl.*
    ,t.*
FROM dbo.AlterTest2 t
CROSS APPLY sys.fn_PhysLocCracker(%%physloc%%) pl
GO
DBID   file_id     page_id     slot_id     ID          col1  col2  col3
------ ----------- ----------- ----------- ----------- ----- ----- -----------
16     1           411         0           1           aaa   bbb   587800818
16     1           411         1           2           aaa   bbb   1396332306
16     1           412         0           3           aaa   bbb   844570652
16     1           412         1           4           aaa   bbb   1332601405
16     1           413         0           5           ccc   ddd   2059368981
16     1           413         1           6           ccc   ddd   1449062892
16     1           414         0           7           ccc   ddd   267569086
16     1           414         1           8           ccc   ddd   1325350591

We can see, that the new table has no wasted space and all pages are now allocated by two records.

Of course if we there are some foreign keys and indexes than those will have to be recreated. Anyway this will cost much less I/O and processing power than creating and dropping the clustered key

 Conclusion

As we can see fro the examples above, altering the fixed column length and increasing it, even it’s metadata  only operation causes, that the originally allocated space is dropped and new space is allocated in the row for all newly inserted or updated rows in the table. So be carefull when altering a fixed length columns especially when you are doing multiple alters to a single column as significat space can be wasted. Knowing the fact that the dropped columns have flag is_dropped = 1 in the sys.system_internals_partition_columns, we can use a below query to list all the tables containing DROPPED columns with wasted space.

SELECT distinct
    p.partition_id,
    p.object_id,
    o.name as table_name
FROM sys.system_internals_partitions p
INNER JOIN sys.objects o on p.object_id = o.object_id
INNER JOIN sys.system_internals_partition_columns pc ON p.partition_id = pc.partition_id
WHERE pc.is_dropped = 1
partition_id         object_id   table_name
-------------------- ----------- -----------
72057594040025088    1253579504  AlterTest2
72057594040090624    1269579561  AlterTest

MS SQL 2012 Window functions introduction

Among lot of new features introduced in SQL Server 2012 also a new Windowing functions were introduced. The new functionality allow us to use the ORDER BY clause in the OVER clause with aggregate functions and also new ROWS and RANGE clauses were introduced to limit rows. The ORDER BY allow us define the order of rows processing and the ROWS/RANGE clauses put limits on the rows being processed in partition. All the details related to the OVER clause you can find on MSDN: OVER Clause (Transact-SQL).

ROWS/RANGE clause

The ROWS clause limits the rows in a parittion by specifying a fixed number of rows preceding or folowing the current rows. The rows preceeding and following are determined by the order specified in the ORDER BY clause.

The limit can be specified by serveral methods:

  • <unsigned integer> PRECEDING -fixed number of preceding rows
  • CURRENT ROW – representing current row being processed
  • UNBOUNDED PRECEDING – all previous records
  • <unsigned integer> FOLLOWING – fixed number of following rows
  • UNBOUNDED FOLLOWING – all rows following current row

So we can specify the limits like

ROWS BETWEEN 3 PRECEEDING AND 1 FOLLOWING
ROWS BETWEEN UNBOUNDED PRECEEDING AND CURRENT ROW
ROWS BETWEEN CURRENT ROW AND 3 FOLLOWING

RANGE BETWEEN UNBOUNDED PRECEEDING AND CURRENT ROW
RANGE BETWEEN CURRENT ROW AND UNBOUNDED FOLLOWING
RENGE CURRENT ROW

The RANGE clause can be only used with the UNBOUNDED limit and CURRENT ROW. The difference between ROWS and RANGE clause is, that ROWS works with physical rows and RANGE works with range of rows based on the current row value in the terms of ORDER BY clause. This means that for ROWS clause the CURRENT ROW represents the only current row being processed. For RANGE the CURRENT ROW represents all the rows with the same value in the fields specified in the ORDER BY clause within current partition as the current row being processed. So if we use RANGE and multiple rows have the same rank in the terms of order within the partition, then all those rows will represent current row.

When there is no ROWS/RANGE clause specified after the ORDER BY clause, then the default RANGE BETWEEN UNBOUNDED PRECEDING AND CURRENT ROW is used by SQL Server.

Samples how to use the window functions

Let’s take a look on a few samples, how we can use the window functions and what results they will provide.

Test data preparation

To be able to test the new functionality

--======================
-- Create test database
--======================
CREATE DATABASE WindowFunctionsTest
GO
USE WindowFunctionsTest
GO

--Create Testing Tables
CREATE TABLE [dbo].[Accounts](
	[TransactionID] [int] IDENTITY(1,1) NOT NULL PRIMARY KEY CLUSTERED,
	[TransactionDate] [datetime] NULL,
	[Balance] [float] NULL
)
GO
CREATE TABLE [dbo].[MultiAccounts](
	[TransactionID] [int] IDENTITY(1,1) NOT NULL PRIMARY KEY CLUSTERED,
	[AccountID] [int] NOT NULL,
	[TransactionDate] [datetime] NULL,
	[Balance] [float] NULL
)
GO
--Fill test tables with data
INSERT INTO [dbo].[Accounts](
	[TransactionDate],
	[Balance]
)
SELECT '2000-1-1', 100 UNION ALL
SELECT '2000-1-1', -50 UNION ALL
SELECT '2000-1-2', 200 UNION ALL
SELECT '2000-1-3', 500 UNION ALL
SELECT '2000-1-4', -200 UNION ALL
SELECT '2000-1-5', 1000 UNION ALL
SELECT '2000-1-5', -300 UNION ALL
SELECT '2000-1-6', -300 UNION ALL
SELECT '2000-1-7', -200 UNION ALL
SELECT '2000-1-8', 2000 UNION ALL
SELECT '2000-1-9', 100 UNION ALL
SELECT '2000-1-10', -50 UNION ALL
SELECT '2000-1-10', 500 UNION ALL
SELECT '2000-1-11', 200 UNION ALL
SELECT '2000-1-12', 200 UNION ALL
SELECT '2000-1-13', 1000 UNION ALL
SELECT '2000-1-14', 1000 UNION ALL
SELECT '2000-1-15', -500 UNION ALL
SELECT '2000-1-15', -300 UNION ALL
SELECT '2000-1-16', 1000 UNION ALL
SELECT '2000-1-17', 1000 UNION ALL
SELECT '2000-1-18', -800 UNION ALL
SELECT '2000-1-19', 2000 UNION ALL
SELECT '2000-1-20', -1000
GO

INSERT [dbo].[MultiAccounts] (
	[AccountID],
	[TransactionDate],
	[Balance]
)
SELECT 1, '2000-1-1', 100 UNION ALL
SELECT 1, '2000-1-1', -50 UNION ALL
SELECT 1, '2000-1-2', 200 UNION ALL
SELECT 1, '2000-1-3', 500 UNION ALL
SELECT 1, '2000-1-4', -200 UNION ALL
SELECT 1, '2000-1-5', 1000 UNION ALL
SELECT 1, '2000-1-5', -300 UNION ALL
SELECT 1, '2000-1-6', -300 UNION ALL
SELECT 1, '2000-1-7', -200 UNION ALL
SELECT 2, '2000-1-1', 2000 UNION ALL
SELECT 2, '2000-1-2', 100 UNION ALL
SELECT 2, '2000-1-3', -50 UNION ALL
SELECT 2, '2000-1-4', 500 UNION ALL
SELECT 2, '2000-1-5', 200 UNION ALL
SELECT 2, '2000-1-6', 200 UNION ALL
SELECT 2, '2000-1-7', 1000 UNION ALL
SELECT 2, '2000-1-7', 1000 UNION ALL
SELECT 3, '2000-1-1', 800 UNION ALL
SELECT 3, '2000-1-2', -300 UNION ALL
SELECT 3, '2000-1-3', 1000 UNION ALL
SELECT 3, '2000-1-4', 1000 UNION ALL
SELECT 3, '2000-1-5', -800 UNION ALL
SELECT 3, '2000-1-6', 2000 UNION ALL
SELECT 3, '2000-1-7', -1000
GO

Window functions samples

If we try any of below queries they will provide the same results

--Using the ROWS clause
SELECT
    [TransactionID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (ORDER BY TransactionDate, TransactionID ROWS BETWEEN UNBOUNDED PRECEDING AND CURRENT ROW) AS CummulativeBalance
FROM [dbo].[Accounts]
ORDER BY TransactionDate, TransactionID
GO
--The same as abowe the ROWS UNBOUNDED PRECEDING will be completed by SQL Server to ROWS BETWEEN UNBOUNDED PRECEDING AND CURRENT ROW
--If we specify only the left boundary, SQL Servers automaticaly fills the right BOUNDARY
SELECT
    [TransactionID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (ORDER BY TransactionDate, TransactionID ROWS UNBOUNDED PRECEDING ) AS CummulativeBalance
FROM [dbo].[Accounts]
ORDER BY TransactionDate, TransactionID
GO
--Using the RANGE Clause
SELECT
    [TransactionID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (ORDER BY TransactionDate, TransactionID RANGE BETWEEN UNBOUNDED PRECEDING AND CURRENT ROW) AS CummulativeBalance
FROM [dbo].[Accounts]
ORDER BY TransactionDate, TransactionID
GO
--The same as above as RANGE UNBOUNDED PRECEDING AND CURRENT ROW will be complete by SQL Server as RANGE BETWEEN UNBOUNDED PRECEDING AND CURRENT ROW
--If we specify only the left boundary, SQL Servers automaticaly fills the right BOUNDARY
SELECT
    [TransactionID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (ORDER BY TransactionDate, TransactionID RANGE UNBOUNDED PRECEDING ) AS CummulativeBalance
FROM [dbo].[Accounts]
ORDER BY TransactionDate, TransactionID
GO
--NO ROWS/RANGE Clause (SQL Server will use the DEFAULT RANGE BETWEEN UNBOUNDED PRECEDING AND CURRENT ROW
SELECT
    [TransactionID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (ORDER BY TransactionDate, TransactionID) AS CummulativeBalance
FROM [dbo].[Accounts]
ORDER BY TransactionDate, TransactionID
GO

Results are below and we can see, a correct cumulative balance is calculated.

TransactionID TransactionDate         Balance                CummulativeBalance
------------- ----------------------- ---------------------- ----------------------
1             2000-01-01 00:00:00.000 100                    100
2             2000-01-01 00:00:00.000 -50                    50
3             2000-01-02 00:00:00.000 200                    250
4             2000-01-03 00:00:00.000 500                    750
5             2000-01-04 00:00:00.000 -200                   550
6             2000-01-05 00:00:00.000 1000                   1550
.             .                       .                      .
.             .                       .                      .
.             .                       .                      .
20            2000-01-16 00:00:00.000 1000                   5900
21            2000-01-17 00:00:00.000 1000                   6900
22            2000-01-18 00:00:00.000 -800                   6100
23            2000-01-19 00:00:00.000 2000                   8100
24            2000-01-20 00:00:00.000 -1000                  7100

ROWS clause with not unique order

SELECT
    [TransactionID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (ORDER BY TransactionDate ROWS BETWEEN UNBOUNDED PRECEDING AND CURRENT ROW) AS CummulativeBalance
FROM [dbo].[Accounts]
ORDER BY TransactionDate
GO

Results will be the same as in previous example. They are the same because there is no parallelism and we have CLUSTERED INDEX on the TransactionID (otherwise the final order could be different because the order of rows with the same TransactionDate is not guaranteed here.

TransactionID TransactionDate         Balance                CummulativeBalance
------------- ----------------------- ---------------------- ----------------------
1             2000-01-01 00:00:00.000 100                    100
2             2000-01-01 00:00:00.000 -50                    50
3             2000-01-02 00:00:00.000 200                    250
4             2000-01-03 00:00:00.000 500                    750
5             2000-01-04 00:00:00.000 -200                   550
6             2000-01-05 00:00:00.000 1000                   1550
7             2000-01-05 00:00:00.000 -300                   1250
.             .                       .                      .
.             .                       .                      .
.             .                       .                      .
20            2000-01-16 00:00:00.000 1000                   5900
21            2000-01-17 00:00:00.000 1000                   6900
22            2000-01-18 00:00:00.000 -800                   6100
23            2000-01-19 00:00:00.000 2000                   8100
24            2000-01-20 00:00:00.000 -1000                  7100

RANGE Clause with not unique order

SELECT
    [TransactionID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (ORDER BY TransactionDate RANGE BETWEEN UNBOUNDED PRECEDING AND CURRENT ROW) AS CummulativeBalance
FROM [dbo].[Accounts]
ORDER BY TransactionDate, TransactionID
GO

Here we see, that the results are quite different. The final sum is the same, but the intermediate are not.

TransactionID TransactionDate         Balance                CummulativeBalance
------------- ----------------------- ---------------------- ----------------------
1             2000-01-01 00:00:00.000 100                    50
2             2000-01-01 00:00:00.000 -50                    50
3             2000-01-02 00:00:00.000 200                    250
4             2000-01-03 00:00:00.000 500                    750
5             2000-01-04 00:00:00.000 -200                   550
6             2000-01-05 00:00:00.000 1000                   1250
7             2000-01-05 00:00:00.000 -300                   1250
8             2000-01-06 00:00:00.000 -300                   950
.             .                       .                      .
.             .                       .                      .
.             .                       .                      .
17            2000-01-14 00:00:00.000 1000                   5700
18            2000-01-15 00:00:00.000 -500                   4900
19            2000-01-15 00:00:00.000 -300                   4900
20            2000-01-16 00:00:00.000 1000                   5900
21            2000-01-17 00:00:00.000 1000                   6900
22            2000-01-18 00:00:00.000 -800                   6100
23            2000-01-19 00:00:00.000 2000                   8100
24            2000-01-20 00:00:00.000 -1000                  7100

Here we can see, that the RANGE works as described above. All rows with the same value in the ORDER BY clause are considered as current row. Therefore for the dates ‘2000/01/01’ ,  ‘2000/01/05’ and ‘2000/01/15’ the values for each date are the same.

Working with FOLLOWING Rows

All the examples above worked with current row and all previous rows. Except this we can even work with rows following current row in particular order.

Here are a few other examples incorporating also FOLLOWING rows.

--Sum of current row and all following rows
SELECT
    [TransactionID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (ORDER BY TransactionDate, TransactionID ROWS BETWEEN CURRENT ROW AND UNBOUNDED FOLLOWING) AS CummulativeBalance
FROM [dbo].[Accounts]
ORDER BY TransactionDate, TransactionID

--SUM of 1 preceding, current and one following row
SELECT
    [TransactionID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (ORDER BY TransactionDate, TransactionID ROWS BETWEEN 1 PRECEDING AND 1 FOLLOWING) AS CummulativeBalance
FROM [dbo].[Accounts]
ORDER BY TransactionDate, TransactionID

--SUM of all rows in each row
SELECT
    [TransactionID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER () AS FinalBalance
FROM [dbo].[Accounts]
ORDER BY TransactionDate, TransactionID

Example with Partitioning results

In previous examples we have worked with single partition. The OVER clause also allows partitioning the results. So let see some a few examples with partitioning.

--Sum of current row and all following rows partitioned, by AccountID
SELECT
    [TransactionID]
	,[AccountID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (PARTITION BY [AccountID] ORDER BY TransactionDate, TransactionID ROWS BETWEEN CURRENT ROW AND UNBOUNDED FOLLOWING) AS CummulativeBalance
FROM [dbo].[MultiAccounts]
ORDER BY AccountID, TransactionDate, TransactionID

--SUM of 1 preceding, current and one following row, partitioned by AccountID
SELECT
    [TransactionID]
	,[AccountID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (PARTITION BY [AccountID] ORDER BY TransactionDate, TransactionID ROWS BETWEEN 1 PRECEDING AND 1 FOLLOWING) AS CummulativeBalance
FROM [dbo].[MultiAccounts]
ORDER BY AccountID, TransactionDate, TransactionID

--SUM of all rows in each row
SELECT
    [TransactionID]
	,[AccountID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (PARTITION BY [AccountID]) AS FinalBalance
FROM [dbo].[MultiAccounts]
ORDER BY AccountID, TransactionDate, TransactionID

--SUM of all preceeding and current row, partitioned by AccountID order is based only on TransactionDate - using RANGE
SELECT
    [TransactionID]
	,[AccountID]
    ,[TransactionDate]
    ,[Balance]
    ,SUM(Balance) OVER (PARTITION BY [AccountID] ORDER BY TransactionDate RANGE BETWEEN UNBOUNDED PRECEDING AND CURRENT ROW) AS CummulativeBalance
FROM [dbo].[MultiAccounts]
ORDER BY AccountID, TransactionDate

When to use ROWS and when RANGE

Now we can ask, when we should use the ROWS clause and when RANGE clause to limit the rows. The answer comes fro the definition how the ROWS and RANGE clauses works. As described, ROWS works with each unique rows and RANGE handles multiple rows with the same order position as current row.

So in case the combination of fields specified in the ORDER BY clause does not uniquely specify the order of rows (as in case of examples above when only TransactionDate was used), then you should use RANGE, as the processing order of rows with the same order position is not guaranteed. In case the rows are uniquely identified, then ROWS should be used as there are no rows with the same order in the partition.

Conclusion

The new windowing functions brings new possibilities in writing T-SQL queries can simplify a lot of tasks which were problematic to write without these constructs. It allow us to bypass the recursive CTE, other solutions for calculation of running totals or averages without knocking down the server and also allow us to bypass quirky updates, CLR solutions which have some pitfalls when are used.

In my next post I will take a closer look on the Running Totals problem when using this new windowing functionality. Also I will take a closer look on the query plans produced by those constructs and give some advices for using them.

Querying Active Directory on SQL Server using T-SQL

You may come to a situation when you need to retrieve list of users, groups or other information from Windows Active Directory (AD) or another LDAP (Lightweight Directory Access Protocol) from within SQL Server.  You may want to store the information from AD in SQL Server tables for later use, or for example determine list of users belonging to particular group etc..

There are basically 3 ways of accessing the Active Directory on SQL Server.

  1. Use Linked Server
  2. User OPENROWSET statement
  3. Using CLR

This article will focus on Querying the Active Directory using the first 2 options. The CLR way is describe in my next article Querying Active Directory on SQL Server using CLR.

Access Active Directory using Linked Server

First I will focus on the Linked Server way to access the AD. So the first step is to create a Linked Server. Tis can be done using the sp_addlinkedserver system stored procedure or using Management Studio and we will use the OLE DB Provider for Microsoft Directory Services (ADSDSOObject).

Creating the Linked Server using the sp_addlinkedserver system stored procedure

To get the linked server working we need to add the linked server itself and also provide credentials to be used by linked server. Here we have two possibilities – use the login’s current security context – this mean use credentials of currently authenticated user (will not work for SQL Server authentication) or provide some AD account credentials to access the linked server.

EXEC sp_addlinkedserver @server = N'ADSI', @srvproduct=N'Active Directory Service Interfaces', @provider=N'ADSDSOObject', @datasrc=N'adsdatasource'

Prior we can use the linked server we have to add a login to that linked server which will be used to authenticate against AD. There are three possibilities:

--Use current user security context (Linked server will use security context of currently autheticated user
EXEC sp_addlinkedsrvlogin @rmtsrvname=N'ADSI',@useself=N'True',@locallogin=NULL,@rmtuser=NULL,@rmtpassword=NULL

--Use one remote account for all users (Linked server will be available to all users) and will use 'DOMAINUserAccount' for authetication to AD
EXEC sp_addlinkedsrvlogin @rmtsrvname=N'ADSI',@useself=N'False',@locallogin=NULL,@rmtuser=N'DOMAINUserAccount',@rmtpassword=N'DomainAccountPassword'

--The Linked Server will be available to SQL Server Login 'SQL Server Login Name' and will use the 'DomainUserAccount' for authetication to AD
EXEC sp_addlinkedsrvlogin @rmtsrvname=N'ADSI',@useself=N'False',@locallogin=N'SQL Server Login Name',@rmtuser=N'DOMAINUserAccunt',@rmtpassword=N'DomainAccountPassword'
Creating the Linked Server using Management Studio

Create Linked Server Step 1Create Linked Server Step 2Create Linked Server Step 3

Querying AD using the Linked Server

Once we have created the linked server we can start querying the AD and we have two possibilities to construct the query against AD (LDAP).

  1. Use SQL Dialect (MSDN)
  2. Use LDAP Dialect (MSDN)

I will show some sample queries using both dialect and details you can find on the above links.

SQL Dialect

SQL Dialect uses the constructs of SQL language and we can write queries against the AD

--Select all groups
SELECT
*
FROM OPENQUERY(ADSI,'SELECT cn, ADsPath FROM ''LDAP://DC=Fabricam,DC=com'' WHERE objectCategory=''group''')

--Select all users
SELECT
*
FROM OPENQUERY(ADSI,'SELECT cn, ADsPath FROM ''LDAP://OU=Sales,DC=Fabricam,DC=com'' WHERE bjectCategory=''person'' AND objectClass=''user''')

Be aware, the the LDAP is case sensitive, so you have to write LDAP:// and not ldap:// otherwise you will not receive any results. Also remember that the LDAP path needs to be enclosed in single quotes and therefore when it is specified in the OPENQUERY statement, it needs to be double single quoted as in example.

Also remember, that LDAP query returns only first 1000 records matching the specified conditions. Once the limit is met, you will receive and error message. You can limit the number of records using the TOP clause to not receive the error. To receive more than 1000 records is possible by using pagination, but it’s quite problematic in T-SQL and I will show this method in the upcoming article which will focus on getting AD data using CLR.

LDAP Dialect

As mentioned above, the other option to make query against the AD is using the LDAP dialect and details about the dialect you can find on the link above. Details how you write the condition in LDAP dialect you can find on MSDN Search Filter Syntax. Using the LDAP dialect we have a greater possibilities in writing conditions, which allow us easily retrieve members of AD Groups etc..

--Select all groups
SELECT
*
FROM OPENQUERY(ADSI,'<LDAP://DC=Fabricam,DC=com>;(&(objectCategory=group));cn,ADsPath;subtree')

--Select all users
SELECT
*
FROM OPENQUERY(ADSI,'<LDAP://OU=Sales,DC=Fabricam,DC=com>;(&(objectCategory=person)(objectClass=user));cn,ADsPath;subtree')

--Select all users belonging to group 'MyGroup'
SELECT
*
FROM OPENQUERY(ADSI,'<LDAP://DC=Fabricam,DC=com>;(&(objectCategory=user)(objectClass=user)(memberOf=MyGroups,OU=Security Groups,OU=Groups,DC=Fabricam,DC=com));cn,ADsPath;subtree')

Access Active Directory using OPENROWSET statement

The method of accessing Active Directory using the OPENROWSET statement is similar to the Linked Server solution. The difference is, that we do not have to create the linked server, but instead of this we provide all the information related to driver, login etc. directly as parameters of the OPENROWSET statement.

Again we have the possibilities to use SQL Dialect or LDAP dialect whatever suits your needs better. Here are some Examples.

--Select all Groups which name starts with "D" (SQL Dialect)
SELECT
*
FROM OPENROWSET('ADSDSOObject', '','SELECT cn, ADsPath FROM ''LDAP://DC=Fabricam,DC=com'' WHERE objectCategory=''group'' AND cn=''D*''')


--Select all users (LDAP Dialect) providing also credentials and flags
SELECT
*
FROM OPENROWSET('ADSDSOObject', 'User ID=UserName;Password=UserPassword;ADSI Flag=0x11;','<LDAP://OU=Sales,DC=Fabricam,DC=com>;(&(objectCategory=user)(objectClass=user));cn,ADsPath;subtree')

In the second example with LDAP Dialect I’ve used also an “ADSI Flag” option. This option specifies binding authentication option and can be a combination of values from the ADS_AUTHENTICATION_ENUM.

Conclusion

The ADSI interface provides us an easy and simple way how to query Active Directory from SQL Server directly sing T-SQL commands. The biggest limitation of that approach is, that it cannot return more than 1000 records in a single batch. This is possible using a Paged Search, but unfortunately this is not available in the T-SQL approach. Although we are limited to 1000 records per batch, we can partially avoid this limitation by adding additional conditions to the query e.g. retrieving all users in batches by the first letter of Common Name etc.. The real power in querying AD brings CLR solution described in Querying Active Directory on SQL Server using CLR.

Querying agent job status, executing and waiting for job completion from within T-SQL

In this article I would like to describe how easily you can query an Agent Job status from within T-SQL command and also how it is possible to execute an agent job and wait for it’s completion.

It can happen, that you do not have access to the Job Activity Monitor and would like to check the status of particular job or simply you would like to query the status to know whether the job finished or not.

For this purposes you can crate a very simple function in the [msdb].

USE [msdb]
GO
-- =============================================
-- Author:      Pavel Pawlowski
-- Create date: 2009/08/14
-- Description: Gets state of particular Job
--
-- -2 = Job was not Found
-- -1 = Job is Disabled
--  0 = Failed
--  1 = Succeeded
--  2 = Retry
--  3 = Canceled
--  4 = In progress
--  5 = Disabled
--  6 = Idle
-- =============================================
CREATE FUNCTION [dbo].[fn_GetJobStatus] (
    @pJobName varchar(100)
)
RETURNS int
AS
BEGIN
    DECLARE @status int

    SELECT
        @status = CASE
            WHEN O.enabled = 0 THEN -1
            WHEN OA.run_requested_date IS NULL THEN 6
            ELSE ISNULL(JH.RUN_STATUS, 4)
        END
    FROM MSDB.DBO.SYSJOBS O
    INNER JOIN MSDB.DBO.SYSJOBACTIVITY OA ON (O.job_id = OA.job_id)
    INNER JOIN (SELECT MAX(SESSION_ID) AS SESSION_ID FROM MSDB.DBO.SYSSESSIONS ) AS S ON (OA.session_ID = S.SESSION_ID)
    LEFT JOIN MSDB.DBO.SYSJOBHISTORY JH ON (OA.job_history_id = JH.instance_id)
    WHERE O.name = @pJobName

    RETURN ISNULL(@status, -2)
END
GO

This function queries several tables from [msdb] to retrieve the status and takes a job name as parameter. Return codes are described in the T-SQL above and codes 2 and 4 are representing a job, which is currently running. Where 2 represents job, which is running in retry mode after previous failure.

This function we can use for writing a procedure, which will allow us to wait for it’s completion.

USE [msdb]
GO
-- =============================================
-- Author:      Pavel Pawlowski
-- Create date: 2009/08/14
-- Description: Waits for a Job Completion
--
-- @pStatusRequestFrequence defines delay between requesting status of the Job in seconds.
--
--Returns values:
-- -2 = Job was not Found
-- -1 = Job is Disabled
--  0 = Failed
--  1 = Succeeded
--  2 = Retry
--  3 = Canceled
--  4 = In progress
--  5 = Disabled
--  6 = Idle
-- =============================================
CREATE PROCEDURE [dbo].[usp_WaitForJob]
    @pJobName varchar(100),
    @pStatusRequestFrequency tinyint = 5,
    @pWaitInitialIdle bit = 1
AS
BEGIN
    SET NOCOUNT ON;
    DECLARE @hours int
    DECLARE @mins int
    DECLARE @delay varchar(8)
    DECLARE @status int

    SET @hours = ROUND(@pStatusRequestFrequency / 3600, 0, 1)
    SET @pStatusRequestFrequency = @pStatusRequestFrequency - (@hours * 3600)
    SET @mins = ROUND(@pStatusRequestFrequency / 60, 0, 1)
    SET @pStatusRequestFrequency = @pStatusRequestFrequency - (@mins * 60)

    SET @delay = RIGHT('00' + CONVERT(varchar(2), @hours), 2) + ':' + RIGHT('00' + CONVERT(varchar(2), @mins), 2) + ':' + RIGHT('00' + CONVERT(varchar(2), @pStatusRequestFrequency), 2)

    SET @status = 4
    WHILE (@status IN (2, 4))
    BEGIN
        SET @status = dbo.fn_GetJobStatus(@pJobName)
        IF (@status IN (2, 4) OR (@status = 6 AND @pWaitInitialIdle = 1) )
        BEGIN
            WAITFOR DELAY @delay
            SET @pWaitInitialIdle = 0
        END
    END

    RETURN @status
END

The procedure executes periodically the above function to get execution status of the job. and when it detects that it is not running, it returns the status of the job. The procedure takes again a job name as parameter and additional two parameters. One to specify the delays between the check for the execution status (by default 5) and an argument specifying whether wait for completion even querying for the first time and the first return value was “Idle”. It can happen, when you start the job and immediately query status, that the state is not reflected in the [msdb] system tables.

Finally at the end we can create a stored procedure for executing the job itself. It will use the previous stored procedure for waiting and the function for querying the status prior execution of the job.

-- =============================================
-- Author:      Pavel Pawlowski
-- Create date: 2009/08/14
-- Description: Runs Particular Job
-- Start Options:
--  0 = if job is already running, do not run job and finish
--  1 = if job is already running, wait for completion and then run it again

-- Return Options:
--  0 = Start Job and wait for job completion
--  1 = Start Job and return from procedure

--Returns values:
-- -2 = Job was not Found
-- -1 = Job is Disabled
--  0 = Failed
--  1 = Succeeded
--  2 = Retry
--  3 = Canceled
--  4 = In progress
--  5 = Disabled
--  6 = Idle

-- @pStatusRequestFrequence defines delay between requesting status of the Job in seconds.
-- =============================================
CREATE PROCEDURE [dbo].[usp_RunJob]
    @pJobName varchar(100),
    @pStartOption int = 0,
    @pReturnOption int = 0,
    @pStatusRequestFrequency tinyint = 5
AS
BEGIN
    SET NOCOUNT ON;
    DECLARE @status int

    SET @status = dbo.fn_GetJobStatus(@pJobName)

    IF (@status IN (2, 4) AND @pStartOption = 1)
        EXEC @status = dbo.usp_WaitForJob @pJobName, @pStatusRequestFrequency

    IF (@status IN (0, 1, 3, 6))
    BEGIN
        EXEC MSDB.dbo.sp_start_job @pJobName

        IF (@pReturnOption <> 1)
            EXEC @status = dbo.usp_WaitForJob @pJobName, @pStatusRequestFrequency
        ELSE
            SET @status = dbo.fn_GetJobStatus(@pJobName)
    END

    RETURN @status
END

This procedure again takes several parameter including the job name to be executed. It has also option whether to wait for the job completion or not and how to handle situation if the job is already running when this procedure is executed.

You can use this mechanism also e.g. for executing Integration Services Package from within T-SQL. You only need to create a job for that package, which will have no schedule. Then using the usp_RunJob you start the job, which takes care about execution of the package itself.

Cloning user rights in database

update: Check new post SQL Server – Cloning User Rights – updated sp_CloneRights on GitHub

Some times it could happen, that you need to create a new database user, which will have exactly the same right as another existing user.

In ideal scenario, you will have all the necessary rights assigned to a database roles, and then when you create the new user, you simply add the user to appropriate roles to grant all the necessary rights.

This is ideal scenario, which is not always met, especially when you have to manage the server after somebody else, who didn’t used roles for granting rights.

In such scenario a below system stored stored procedure can be very handful.

USE [master]
GO
--============================================
-- Author:      Pavel Pawlowski
-- Created:     2010/04/16
-- Description: Copies rights of old user to new user
--==================================================
CREATE PROCEDURE sp_CloneRights (
    @oldUser sysname, --Old user from which to copy right
    @newUser sysname, --New user to which copy rights
    @printOnly bit = 1, --When 1 then only script is printed on screen, when 0 then also script is executed, when NULL, script is only executed and not printed
    @NewLoginName sysname = NULL --When a NewLogin name is provided also a creation of user is part of the final script
)
AS
BEGIN
    SET NOCOUNT ON

    CREATE TABLE #output (
        command nvarchar(4000)
    )

    DECLARE
        @command nvarchar(4000),
        @sql nvarchar(max),
        @dbName nvarchar(128),
        @msg nvarchar(max)

    SELECT
        @sql = N'',
        @dbName = QUOTENAME(DB_NAME())

    IF (NOT EXISTS(SELECT 1 FROM sys.database_principals where name = @oldUser))
    BEGIN
        SET @msg = 'Source user ' + QUOTENAME(@oldUser) + ' doesn''t exists in database ' + @dbName
        RAISERROR(@msg, 11,1)
        RETURN
    END

    INSERT INTO #output(command)
    SELECT '--Database Context' AS command UNION ALL
    SELECT    'USE' + SPACE(1) + @dbName UNION ALL
    SELECT 'SET XACT_ABORT ON'

    IF (ISNULL(@NewLoginName, '') <> '')
    BEGIN
        SET @sql = N'USE ' + @dbName + N';
        IF NOT EXISTS (SELECT 1 FROM sys.database_principals WHERE name = @newUser)
        BEGIN
            INSERT INTO #output(command)
            SELECT ''--Create user'' AS command

            INSERT INTO #output(command)
            SELECT
                ''CREATE USER '' + QUOTENAME(@NewUser) + '' FOR LOGIN '' + QUOTENAME(@NewLoginName) +
                    CASE WHEN ISNULL(default_schema_name, '''') <> '''' THEN '' WITH DEFAULT_SCHEMA = '' + QUOTENAME(dp.default_schema_name)
                        ELSE ''''
                    END AS Command
            FROM sys.database_principals dp
            INNER JOIN sys.server_principals sp ON dp.sid = sp.sid
            WHERE dp.name = @OldUser
        END'

        EXEC sp_executesql @sql, N'@OldUser sysname, @NewUser sysname, @NewLoginName sysname', @OldUser = @OldUser, @NewUser = @NewUser, @NewLoginName=@NewLoginName
    END

    INSERT INTO #output(command)
    SELECT    '--Cloning permissions from' + SPACE(1) + QUOTENAME(@OldUser) + SPACE(1) + 'to' + SPACE(1) + QUOTENAME(@NewUser)

    INSERT INTO #output(command)
    SELECT '--Role Memberships' AS command

    SET @sql = N'USE ' + @dbName + N';
    INSERT INTO #output(command)
    SELECT ''EXEC sp_addrolemember @rolename =''
        + SPACE(1) + QUOTENAME(USER_NAME(rm.role_principal_id), '''''''') + '', @membername ='' + SPACE(1) + QUOTENAME(@NewUser, '''''''') AS command
    FROM    sys.database_role_members AS rm
    WHERE    USER_NAME(rm.member_principal_id) = @OldUser
    ORDER BY rm.role_principal_id ASC'

    EXEC sp_executesql @sql, N'@OldUser sysname, @NewUser sysname', @OldUser = @OldUser, @NewUser = @NewUser

    INSERT INTO #output(command)
    SELECT '--Object Level Permissions'

    SET @sql = N'USE ' + @dbName + N';
    INSERT INTO #output(command)
    SELECT    CASE WHEN perm.state <> ''W'' THEN perm.state_desc ELSE ''GRANT'' END
        + SPACE(1) + perm.permission_name + SPACE(1) + ''ON '' + QUOTENAME(SCHEMA_NAME(obj.schema_id)) + ''.'' + QUOTENAME(obj.name)
        + CASE WHEN cl.column_id IS NULL THEN SPACE(0) ELSE ''('' + QUOTENAME(cl.name) + '')'' END
        + SPACE(1) + ''TO'' + SPACE(1) + QUOTENAME(@NewUser) COLLATE database_default
        + CASE WHEN perm.state <> ''W'' THEN SPACE(0) ELSE SPACE(1) + ''WITH GRANT OPTION'' END
    FROM    sys.database_permissions AS perm
        INNER JOIN
        sys.objects AS obj
        ON perm.major_id = obj.[object_id]
        INNER JOIN
        sys.database_principals AS usr
        ON perm.grantee_principal_id = usr.principal_id
        LEFT JOIN
        sys.columns AS cl
        ON cl.column_id = perm.minor_id AND cl.[object_id] = perm.major_id
    WHERE    usr.name = @OldUser
    ORDER BY perm.permission_name ASC, perm.state_desc ASC'

    EXEC sp_executesql @sql, N'@OldUser sysname, @NewUser sysname', @OldUser = @OldUser, @NewUser = @NewUser

    INSERT INTO #output(command)
    SELECT N'--Database Level Permissions'

    SET @sql = N'USE ' + @dbName + N';
    INSERT INTO #output(command)
    SELECT    CASE WHEN perm.state <> ''W'' THEN perm.state_desc ELSE ''GRANT'' END
        + SPACE(1) + perm.permission_name + SPACE(1)
        + SPACE(1) + ''TO'' + SPACE(1) + QUOTENAME(@NewUser) COLLATE database_default
        + CASE WHEN perm.state <> ''W'' THEN SPACE(0) ELSE SPACE(1) + ''WITH GRANT OPTION'' END
    FROM    sys.database_permissions AS perm
        INNER JOIN
        sys.database_principals AS usr
        ON perm.grantee_principal_id = usr.principal_id
    WHERE    usr.name = @OldUser
    AND    perm.major_id = 0
    ORDER BY perm.permission_name ASC, perm.state_desc ASC'

    EXEC sp_executesql @sql, N'@OldUser sysname, @NewUser sysname', @OldUser = @OldUser, @NewUser = @NewUser

    DECLARE cr CURSOR FOR
        SELECT command FROM #output

    OPEN cr

    FETCH NEXT FROM cr INTO @command

    SET @sql = ''

    WHILE @@FETCH_STATUS = 0
    BEGIN
        IF (@printOnly IS NOT NULL)
            PRINT @command

        SET @sql = @sql + @command + CHAR(13) + CHAR(10)
        FETCH NEXT FROM cr INTO @command
    END

    CLOSE cr
    DEALLOCATE cr

    IF (@printOnly IS NULL OR @printOnly = 0)
        EXEC (@sql)

    DROP TABLE #output
END
GO
EXECUTE sp_ms_marksystemobject 'dbo.sp_CloneRights'
GO

The stored procedure allows copying all the objects and database rights from the old user to a new one. It also clones roles membership for the user.

If the @NewLoginName is specified then then it also creates the @newUser in the database for the login specified and then copies the rights.

@printOnly specifies whether the script should be printed, executed automatically or both printed and executed automatically.

As the system is marked as system, it executes in the context of the database in which is executed.

It also allows copying rights among database roles. If you specify as @oldUser a database or application role name, then the rights of that role will be copied to the @newUser. Again the @newUser can be a user name or database/application role name.

For example if you have a Integration services installed and invoke a below script

USE [msdb]
GO
EXEC sp_CloneRights 'db_ssisadmin', 'NewUser'

you will receive a below script for assigning rights.

--Database Context
USE [msdb]
SET XACT_ABORT ON
--Cloning permissions from [db_ssisadmin] to [NewUser]
--Role Memberships
--Object Level Permissions
GRANT DELETE ON [dbo].[sysssislog] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_get_dtsversion] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_make_dtspackagename] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_add_dtspackage] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_drop_dtspackage] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_reassign_dtspackageowner] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_get_dtspackage] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_addlogentry] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_listpackages] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_enum_dtspackages] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_listfolders] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_deletepackage] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_deletefolder] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_getpackage] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_getfolder] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_putpackage] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_checkexists] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_addfolder] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_renamefolder] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_setpackageroles] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_ssis_getpackageroles] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_log_dtspackage_begin] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_log_dtspackage_end] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_log_dtsstep_begin] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_log_dtsstep_end] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_log_dtstask] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_enum_dtspackagelog] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_enum_dtssteplog] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_enum_dtstasklog] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_dump_dtslog_all] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_dump_dtspackagelog] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_dump_dtssteplog] TO [NewUser]
GRANT EXECUTE ON [dbo].[sp_dump_dtstasklog] TO [NewUser]
GRANT INSERT ON [dbo].[sysssislog] TO [NewUser]
GRANT REFERENCES ON [dbo].[sysssislog] TO [NewUser]
GRANT SELECT ON [dbo].[sysssislog] TO [NewUser]
GRANT UPDATE ON [dbo].[sysssislog] TO [NewUser]
--Database Level Permissions

Hope you will find this script useful and hope it will save you a lot of work when cloning rights.

It saved me several times, when I come to an existing database with several hundreds of tables with rights assigned on the object level and I had to introduce a new user with exactly the same rights as an existing one.

One thing needs to be mentioned for end. The procedure clones only object and database right. It doesn’t clone right for system objects, assemblies etc., but you can easily extend the procedure to cover also this this.

This procedure is inspired by  a script I found in past somewhere on internet.

Automating CRUD procedures generation using T-SQL

CRUD procedures represent a good way how to secure the database. When using CRUD procedures, no user has direct access to the database tables and instead of this is forced to use parameterized procedures for all data manipulations called CRUD procedures. CRUD is acronym for Create Read Update Delete.

CRUD procedures have a lot of advantages from which I can name several:

  • You do not need to grant rights directly to tables and in this way you hide the physical tables structure to users.
  • You can encapsulate some logic into the procedures and then when something needs to be changed, you simply modify a procedure and do not need to rebuild the application.
  • You hide the SQL logic encapsulated in stored procedures from end user.
  • You protect your SQL server against SQL injection as all data using the CRUD procedures has to be passed as parameters and in this way you drastically decrease a chance for the SQL injection.

The main disadvantage of CRUD procedures is the overhead which SQL developer has to do as for each table or group of several tables it is necessary separate stored procedures for the data manipulation.

There are several tools and plugins into visual studio, which simplifies creation of the CRUD procedures, but in this article I would like to show a possible way how to automate creation of the CRUD procedures using pure T-SQL.

The automation will be handled by a custom system stored procedure, which generate all the necessary code or directly create all the CRUD procedures for a database table.

This article describes how to crate a system stored procedure sp_makeCRUD, which will take 4 parameters @objectName, @executionMode, @dropExistingProcedures and @outputIdentityCalcField. The @objectName represents a table for which the CRUD procedures will be generated, @executionMode will represents execution mode of the stored procedure and will control whether the code of CRUD procedures will be only printed on scree or whether the generated code will be automatically executed and the CRUD procedures will created. @dropExistingProcedures parameter will specify whether include DROP statement for all procedures to drop eventual existing procedures and @outputIdentityCalcField will control, whether Identity and Calculated fields will be automatically returned as record set for ISERT and UPDATE operations.

CRUD procedures construction

To create a CRUD procedures we need to know all the fields in the table, whether the fields are Identity or calculated fields and also we need to know what fields the primary key is composed from. Also table name and it’s schema will be needed as user can specify the object name without schema or with schema. The CRUD procedures will be created in the same schema as the original table. To retrieve such information various system tables will be used.

Retrieving Object ID, Table Name, Schema Name and DB Name

To retrieve Object ID (ID of the table) and DB Name we will use the OBJECT_ID() and DB_NAME() functions.

SELECT
    @objID = OBJECT_ID(@objectName),
    @dbName = DB_NAME()

Table name and schema name, could be retrieved using system tables sys.objects and sys.schemas.

SELECT
    @schemaName = s.name,
    @tableName = o.name
FROM sys.objects o
INNER JOIN sys.schemas s ON o.schema_id = s.schema_id
WHERE o.object_id = @objId AND o.type = 'U'

Retrieving Table Field and Primary Key

After the object ID is retrieved, it is necessary to retrieve all the table fields, their data types and information whether the field is an IDENTITY field or whether it is Calculated Field. This information is necessary for generating INSERT and UPDATE statements as such fields are not updatable. Also it is necessary to identify fields which are part of the primary key. This fields are necessary for the UPDATE, DELETE and also for SELECT One statements. Fields will be temporarily stored in table variables as they will be accessed several times to construct different fields combinations for each statement and also for creation of procedure parameters.

The retrieval of all fields is quite easy as only access to sys.columns table for field names and sys.types for type names is necessary. The field type is written to the table variable as SQL statement which will be used when generating the procedure parameters.

DECLARE @allFields TABLE (        --Table variable for storing all the table fields
    name sysname,                --field name
    isIdentity bit,                --specifies whether field is INDENTITY
    isCalculated bit,            --specifies whether filed is Calculated field
    fieldType sysname            --Specified data type of the field
)

--Get all table fields and store them in the @allFields table variable for construction of CRUD procedures
INSERT INTO @allFields (
    name,
    isIdentity,
    isCalculated,
    fieldType
)
SELECT
    c.name,
    is_identity,
    is_computed,
    CASE
        WHEN t.name IN (N'char', N'nchar', N'varchar', N'nvarchar') THEN QUOTENAME(t.name) + N'(' + CASE WHEN c.max_length = -1 THEN N'max' ELSE CAST(c.max_length AS sysname) END + N')'
        WHEN t.name IN (N'decimal', N'numeric') THEN QUOTENAME(t.name) + N'(' + CAST(c.precision AS sysname) + N', ' + CAST(c.scale AS sysname) + N')'
        ELSE QUOTENAME(t.name)
    END
FROM sys.columns c
INNER JOIN sys.types t ON c.user_type_id = t.user_type_id
WHERE object_id = @objId

The query to retrieve the fields form which the Primary Key is composed is more complex and to retrieve all the information we need it is necessary to access several system tables. As the Primary Key is enforced by a unique index, the field names can be found using the ID of the columns in unique index by which the primary key is enforced.

DECLARE @pkFields TABLE (        --Table variable for storing fields which are part of primary key
    name sysname,                --field Name
    fieldType sysname            --Specified data type of the field
)

--Get list of Primary Key Fields and store them in @pkFields table variable for construction of CRUD procedures
INSERT INTO @pkFields(
    name,
    fieldType
)
SELECT
    c.name,
    CASE
        WHEN t.name IN (N'char', N'nchar', N'varchar', N'nvarchar') THEN QUOTENAME(t.name) + N'(' + CASE WHEN c.max_length = -1 THEN N'max' ELSE CAST(c.max_length AS sysname) END + N')'
        WHEN t.name IN (N'decimal', N'numeric') THEN QUOTENAME(t.name) + N'(' + CAST(c.precision AS sysname) + N', ' + CAST(c.scale AS sysname) + N')'
        ELSE QUOTENAME(t.name)
    END
FROM sys.key_constraints kc
INNER JOIN sys.indexes i ON kc.parent_object_id = i.object_id AND kc.unique_index_id = i.index_id
INNER JOIN sys.index_columns ic ON i.object_id = ic.object_id AND i.index_id = ic.index_id
INNER JOIN sys.columns c ON ic.object_id = c.object_id AND ic.column_id = c.column_id
INNER JOIN sys.types t ON c.user_type_id = t.user_type_id
WHERE kc.parent_object_id = @objId and kc.type = 'PK'

Generating Columns and Variables Lists

Once the list of all columns is retrieved, the lists of different columns combinations could be generated. For this purpose a SELECT statement with FOR XML PATH clause will be used as this clause greatly simplifies a CSV list generation on SQL 2005 and above. Below is a code for the All Columns

SELECT @allColumns =
    STUFF(REPLACE((SELECT
                        N'            ' + @crlf + N'            ,' + QUOTENAME(c.name)
                    FROM @allFields c
                    FOR XML PATH(N'')
                    ),
            @crlfXML, @crlf),
        1, 27, N'             ')

The spaces are included in the generated string for later final query formatting as it allows the query to be printed in readable form and also when a stored procedure will be generated, it can be later easily modified as the query will contain correct line breaks and indentation. The REPLACE function is used to replace the XML representation of CRLF back to real CRLF characters as the FOR XML PATH in reality produces XML output and translates all the CRLF characters to their XML compliant equivalents.

Generating code of CRUD Procedures

Once all the the combination of columns are generated, the variables with such fields and parameters list can be used to generate the final CRUD procedure. Below is a snippet representing a SELECT procedure.

SET @sql = N'-- =======================================================
-- Author:        ' + QUOTENAME(SUSER_SNAME()) + N'
-- Create date: ' + CONVERT(nvarchar(10), GETDATE(), 111) + N'
-- Description:    Selects records from table ' + QUOTENAME(@schemaName) + '.' + QUOTENAME(@tableName) + N'
-- =======================================================
CREATE PROCEDURE ' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixSelect + N']
' + @selectParams + N'
AS
BEGIN
    SET NOCOUNT ON;

    IF (' + @selectAllIfNullCondition + N') THEN
    BEGIN
        SELECT
' + @allColumns + N'
        FROM ' + QUOTENAME(@schemaName) + N'.' + QUOTENAME(@tableName) + N'
    END
    ELSE
    BEGIN
        SELECT
' + @allColumns + N'
        FROM ' + QUOTENAME(@schemaName) + N'.' + QUOTENAME(@tableName) + N'
        WHERE
' + @selectCondition + N'
    END
END
GO

';

sp_makeCRUD Final Form

Once all the parts of the procedure are prepared it’s possible to construct a final form of the sp_makeCRUD procedure. Below is a complete code for the sp_makeCRUD procedure.

USE [master]
GO
--==========================================================
-- Author: (c) 2011 Pavel Pawlowski
-- Description: Generates CRUD procedures for a table
--
--@objectName = table name with or without schema for which the CRUD procedures should be generated
--
--@executionMode
--  1 = Print the script Only
--  2 = Output the script as recordset using SELECT for longer procedures which is not possible output using PRINT
--  4 = Execute and Commit
--  8 = Execute and Rollback - testing mode
--
--@dropExistingProcedures = 1 | 0
-- specifies whether generate DROP commands for existing objects
--
--@outputIndentityCalcFields = 1 | 0
-- specifies whether Identity and Calculated fields should be OUTPUTed in INSERT and UPDATE
--==========================================================
CREATE PROCEDURE [dbo].[sp_makeCRUD]
    @objectName sysname,
    @executionMode tinyint = 1,
    @dropExistingProcedures bit = 1,
    @outputIndentityCalcFields bit = 1
AS
BEGIN
    SET NOCOUNT ON;
    SET XACT_ABORT ON;

    --variables declaration
    DECLARE
        @objId int,                                 --ID of the Table
        @schemaName sysname,                        --schema Name of the Table
        @tableName sysname,                         --TableName
        @dbName sysname,                            --Database name in which we are creating the procedures
        @crlfXML nchar(7),                          --XML representation of the CLRF
        @crlf nchar(2),                             --CLRF characters
        @procPrefix sysname,                        --CRUD procedures Prefix
        @sql nvarchar(max),                         --SQL code for particular steps
        @msg nvarchar(max),                         --A message
        @suffixSelect sysname,                      --Suffix for SELECT procedure
        @suffixUpdate sysname,                      --Suffix for UPDATE procedure
        @suffixDelete sysname,                      --Suffix for Delete procedure
        @suffixInsert sysname,                      --Suffix for INSERT procedure
        @selectParams nvarchar(max),                --Parameters for SELECT procedure
        @allColumns nvarchar(max),                  --List of All columns in a table for SELECT statement
        @selectAllIfNullCondition nvarchar(max),    --Condition for checking if all parameters in SELECT procedure are NULL
        @selectCondition nvarchar(max),             --SELECT statement condition
        @updateParams nvarchar(max),                --Parameters for UPDATE procedure
        @updateColumns nvarchar(max),               --List of columns for UPDATE statement
        @updateDeleteCondition nvarchar(max),       --Condition for UPDATE and DELETE statement
        @updateOutputCols nvarchar(max),            --List of UPDATE statement output columns to output calculated columns
        @deleteParams nvarchar(max),                --Parameters for DELETE procedure
        @insertParams nvarchar(max),                --Parameters for INSERT procedure
        @insertColumns nvarchar(max),               --List of COLUMNS for INSERT statement
        @insertOutputCols nvarchar(max),            --List of INSERT statement ouptup columns to output IDENTITY and calculated fields
        @insertParamNames nvarchar(max),            --List of parameter names in Insert procedure
        @isTooLongForPrint bit                      --Sores info whether some of the procs is too long for PRINT

    --Declaration of fields Table Variables
    DECLARE @pkFields TABLE (        --Table variable for storing fields which are part of primary key
        name sysname,                --field Name
        fieldType sysname            --Specified data type of the field
    )
    DECLARE @allFields TABLE (
        name sysname,                --field name
        isIdentity bit,              --specifies whether field is INDENTITY
        isCalculated bit,            --specifies whether filed is Calculated field
        fieldType sysname            --Specified data type of the field
    )

    --Table variable for storing scripts for execution
    DECLARE @scripts TABLE (
        id int NOT NULL IDENTITY,
        script nvarchar(max)
    )

    --Check if an execution mode is selected
    IF ((@executionMode & 7) = 0)
    BEGIN
        SET @msg = N'You have to select at at leas one possible execution Mode (@executionMode)
    1 = Print the script Only
    2 = Output the script as SELECT resordset for longer procedures which is not possible output using PRINT
    4 = Execute and Commit
    8 = Execute and Rollback - testing mode

You can also combine the Print and Execute Modes, but you cannot combine both execution modes'
        RAISERROR (@msg, 11, 1)
        RETURN
    END

    IF ((@executionMode & 6) = 6)
    BEGIN
        SET @msg = N'You cannot specify Execute and Commit with Execute and Rollback Together'
        RAISERROR (@msg, 11, 1)
        RETURN
    END

    --populate parameters and constants
    SELECT
        @objID = OBJECT_ID(@objectName),
        @dbName = DB_NAME(),
        @crlfXML = N'
' + NCHAR(10),    --XML Representation of the CR+LF delimiter as we use FOR XML PATH ant this translates the original CR+LF to XML Equivalent. We need it to change it back
        @crlf = NCHAR(13) + NCHAR(10),        --CR+LF delimiter used in script
        @procPrefix = 'usp_CRUD_',            --Specifies prefix to be added to all CRUD procedures
        @suffixSelect = '_S',                --Specifies suffix to be added to the Select Procedure
        @suffixUpdate = '_U',                --Specifies suffix to be added to the Update Procedure
        @suffixDelete = '_D',                --Specifies suffix to be added to the Delete Procedure
        @suffixInsert = '_I'                --Specifies suffix to be added to the Inser Procedure

    --Check whether object exists
    IF @objId IS NULL
    BEGIN
        SET @msg = N'Object "' + @objectName + '" doesnt'' exist in database ' + QUOTENAME(@dbName)
        RAISERROR (@msg, 11, 1)
        RETURN
    END

    --Populate table name and schema name
    SELECT
        @schemaName = s.name,
        @tableName = o.name
    FROM sys.objects o
    INNER JOIN sys.schemas s ON o.schema_id = s.schema_id
    WHERE o.object_id = @objId AND o.type = 'U'

    --check whether object is table
    IF (@tableName IS NULL)
    BEGIN
        SET @msg = N'Object "' + @objectName + '" is not User Table. Creating CRUD procedures is possible only on User Tables.'
        RAISERROR (@msg, 11, 1)
        RETURN
    END

    --Get all table fields and store them in the @allFields table variable for construction of CRUD procedures
    INSERT INTO @allFields (
        name,
        isIdentity,
        isCalculated,
        fieldType
    )
    SELECT
        c.name,
        is_identity,
        is_computed,
        CASE
            WHEN t.name IN (N'char', N'nchar', N'varchar', N'nvarchar') THEN QUOTENAME(t.name) + N'(' + CASE WHEN c.max_length = -1 THEN N'max' ELSE CAST(c.max_length AS sysname) END + N')'
            WHEN t.name IN (N'decimal', N'numeric') THEN QUOTENAME(t.name) + N'(' + CAST(c.precision AS sysname) + N', ' + CAST(c.scale AS sysname) + N')'
            ELSE QUOTENAME(t.name)
        END
    FROM sys.columns c
    INNER JOIN sys.types t ON c.user_type_id = t.user_type_id
    WHERE object_id = @objId

    --Get list of Primary Key Fields and store them in @pkFields table variable for construction of CRUD procedures
    INSERT INTO @pkFields(
        name,
        fieldType
    )
    SELECT
        c.name,
        CASE
            WHEN t.name IN (N'char', N'nchar', N'varchar', N'nvarchar') THEN QUOTENAME(t.name) + N'(' + CASE WHEN c.max_length = -1 THEN N'max' ELSE CAST(c.max_length AS sysname) END + N')'
            WHEN t.name IN (N'decimal', N'numeric') THEN QUOTENAME(t.name) + N'(' + CAST(c.precision AS sysname) + N', ' + CAST(c.scale AS sysname) + N')'
            ELSE QUOTENAME(t.name)
        END
    FROM sys.key_constraints kc
    INNER JOIN sys.indexes i ON kc.parent_object_id = i.object_id AND kc.unique_index_id = i.index_id
    INNER JOIN sys.index_columns ic ON i.object_id = ic.object_id AND i.index_id = ic.index_id
    INNER JOIN sys.columns c ON ic.object_id = c.object_id AND ic.column_id = c.column_id
    INNER JOIN sys.types t ON c.user_type_id = t.user_type_id
    WHERE kc.parent_object_id = @objId and kc.type = 'PK'

    --Check Whether there is primary Key the CRUD works only if there is primary key in the table
    IF (NOT EXISTS(SELECT 1 FROM @pkFields))
    BEGIN
        SET @msg = N'Table "' + @objectName + '" does not have a Primary Key. There must exists a primary key prior generating CRUD procedures.'
        RAISERROR (@msg, 11, 1)
    END

    --list of output columns for INSERT statement (ouptup of Identity and calculated fields)
    SELECT @insertOutputCols =
        STUFF(REPLACE((SELECT
                            N'        ' + @crlf + N'        ,inserted.' + QUOTENAME(c.name)
                        FROM @allFields c
                        WHERE isIdentity = 1 OR isCalculated = 1
                        FOR XML PATH(N'')
                        ),
                @crlfXML, @crlf),
            1, 19, N'         ')

    --list of output columns for UPDATE statement (Calculated fields only)
    SELECT @updateOutputCols =
        STUFF(REPLACE((SELECT
                            N'        ' + @crlf + N'        ,inserted.' + QUOTENAME(c.name)
                        FROM @allFields c
                        WHERE isCalculated = 1
                        FOR XML PATH(N'')
                        ),
                @crlfXML, @crlf),
            1, 19, N'         ')

    --ist of all columns used in the SELECT Statement
    SELECT @allColumns =
        STUFF(REPLACE((SELECT
                            N'            ' + @crlf + N'            ,' + QUOTENAME(c.name)
                        FROM @allFields c
                        FOR XML PATH(N'')
                        ),
                @crlfXML, @crlf),
            1, 27, N'             ')

    --list of columns for UPDATE statement including the equal sign and variable (all columns except indentity and calculated ones)
    SELECT @updateColumns =
        STUFF(REPLACE((SELECT
                            N'        ' + @crlf + N'        ,' + QUOTENAME(c.name) + N' = @' + c.name
                        FROM @allFields c
                        WHERE isIdentity = 0 AND isCalculated = 0
                        FOR XML PATH(N'')
                        ),
                @crlfXML, @crlf),
            1, 19, N'         ')

    --list of columns for INSERT statement (all columns except identity and calculated ones)
    SELECT @insertColumns =
        STUFF(REPLACE((SELECT
                            N'        ' + @crlf + N'        ,' + QUOTENAME(c.name)
                        FROM @allFields c
                        WHERE isIdentity = 0 AND isCalculated = 0
                        FOR XML PATH(N'')
                        ),
                @crlfXML, @crlf),
            1, 19, N'         ')

    --condition for UPDATE and DELETE statement
    SET @updateDeleteCondition =
            STUFF(REPLACE((SELECT
                            N'        ' + @crlf + N'        AND' + @crlf + '        ' + QUOTENAME(c.name) + N' = @' + c.name
                        FROM @pkFields c
                        FOR XML PATH(N'')), @crlfXML, @crlf), 1, 23, N'')

    --IF condition for SELECT statement if all params will be NULL to do not use condition to receive better plans
    SET @selectAllIfNullCondition =
                STUFF((SELECT
                            N' AND @' + c.name + N' IS NULL'
                        FROM @pkFields c
                        FOR XML PATH(N'')), 1, 5, N'')

    --Select condition (for SELECT ONE)
    SET @selectCondition =
        STUFF(REPLACE((SELECT
                            N'            ' + @crlf + N'            AND' + @crlf + N'            (@' + c.name + N' IS NULL OR ' + QUOTENAME(c.name) + N' = @' + c.name + N')'
                        FROM @pkFields c
                        FOR XML PATH(N'')), @crlfXML, @crlf), 1, 31, N'')

    --parameters list for SELECT CRUD procedure
    SELECT @selectParams =
        STUFF(REPLACE((SELECT
                            N',    ' + @crlf + N'    @' + c.name + N' ' + c.fieldType + N' = NULL'
                        FROM @pkFields c
                        FOR XML PATH(N'')
                        ),
                @crlfXML, @crlf),
            1, 11, N'    ')

    --parameters list for DELETE CRUD procedure
    SELECT @deleteParams =
        STUFF(REPLACE((SELECT
                            N',    ' + @crlf + N'    @' + c.name + N' ' + c.fieldType
                        FROM @pkFields c
                        FOR XML PATH(N'')
                        ),
                @crlfXML, @crlf),
            1, 11, N'    ')

    --parameters list for UPDATE CRUD procedure
    SELECT @updateParams =
        STUFF(REPLACE((SELECT
                            N',    ' + @crlf + N'    @' + c.name + N' ' + c.fieldType
                        FROM @allFields c
                        LEFT JOIN @pkFields pk ON c.name = pk.name
                        WHERE (c.isIdentity = 0 AND c.isCalculated = 0) OR pk.name IS NOT NULL
                        FOR XML PATH(N'')
                        ),
                @crlfXML, @crlf),
            1, 11, N'    ')

    --parameters list for INSERT CRUD procedure
    SELECT @insertParams =
        STUFF(REPLACE((SELECT
                            N',    ' + @crlf + N'    @' + c.name + N' ' + c.fieldType
                        FROM @allFields c
                        LEFT JOIN @pkFields pk ON c.name = pk.name
                        WHERE c.isIdentity = 0 AND c.isCalculated = 0
                        FOR XML PATH(N'')
                        ),
                @crlfXML, @crlf),
            1, 11, N'    ')

    --parameter names list for INSERT command in the INSERT CRUD procedure
    SELECT @insertParamNames =
        STUFF(REPLACE((SELECT
                            N'        ' + @crlf + N'        ,@' + c.name
                        FROM @allFields c
                        LEFT JOIN @pkFields pk ON c.name = pk.name
                        WHERE c.isIdentity = 0 AND c.isCalculated = 0
                        FOR XML PATH(N'')
                        ),
                @crlfXML, @crlf),
            1, 19, N'         ')

--USE DB
SET @sql = N'USE ' + QUOTENAME(@dbName) + N'
'
INSERT INTO @scripts(script) VALUES(@sql)

--SELECT PROCEDURE
IF (@dropExistingProcedures = 1)
BEGIN
SET @sql = N'--Drop existing SELECT CRUD Procedure
IF (EXISTS (SELECT * FROM sys.objects WHERE object_id = OBJECT_ID(''' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixSelect + N']'') AND type = ''P''))
    DROP PROCEDURE ' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixSelect +N']
'
INSERT INTO @scripts(script) VALUES(@sql)
END

SET @sql = N'-- =======================================================
-- Author:      ' + QUOTENAME(SUSER_SNAME()) + N'
-- Create date: ' + CONVERT(nvarchar(10), GETDATE(), 111) + N'
-- Description: Selects records from table ' + QUOTENAME(@schemaName) + '.' + QUOTENAME(@tableName) + N'
-- =======================================================
CREATE PROCEDURE ' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixSelect + N']
' + @selectParams + N'
AS
BEGIN
    SET NOCOUNT ON;

    IF (' + @selectAllIfNullCondition + N')
    BEGIN
        SELECT
' + @allColumns + N'
        FROM ' + QUOTENAME(@schemaName) + N'.' + QUOTENAME(@tableName) + N'
    END
    ELSE
    BEGIN
        SELECT
' + @allColumns + N'
        FROM ' + QUOTENAME(@schemaName) + N'.' + QUOTENAME(@tableName) + N'
        WHERE
' + @selectCondition + N'
    END
END
';
INSERT INTO @scripts(script) VALUES(@sql)

--UPDATE PROCEDURE
IF (@dropExistingProcedures = 1)
BEGIN
SET @sql = N'--Drop existing UPDATE CRUD Procedure
IF (EXISTS (SELECT * FROM sys.objects WHERE object_id = OBJECT_ID(''' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixUpdate + N']'') AND type = ''P''))
    DROP PROCEDURE ' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixUpdate + N']
'
INSERT INTO @scripts(script) VALUES(@sql)
END

SET @sql = N'-- =======================================================
-- Author:      ' + QUOTENAME(SUSER_SNAME()) + N'
-- Create date: ' + CONVERT(nvarchar(10), GETDATE(), 111) + N'
-- Description: Updates record in table ' + QUOTENAME(@schemaName) + '.' + QUOTENAME(@tableName) + N'
-- =======================================================
CREATE PROCEDURE ' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixUpdate + N']
' + @updateParams + N'
AS
BEGIN
    SET NOCOUNT ON;

    UPDATE ' + QUOTENAME(@schemaName) + N'.' + QUOTENAME(@tableName) + N' SET
' + @updateColumns + CASE WHEN @outputIndentityCalcFields = 1 AND @updateOutputCols <> N'' AND @updateOutputCols IS NOT NULL THEN N'
    OUTPUT
' + @updateOutputCols
    ELSE N'' END + N'
    WHERE
' + @updateDeleteCondition + N'
END
';
INSERT INTO @scripts(script) VALUES(@sql)

--DELETE PROCEDURE
IF (@dropExistingProcedures = 1)
BEGIN
SET @sql = N'--Drop existing DELETE CRUD Procedure
IF (EXISTS (SELECT * FROM sys.objects WHERE object_id = OBJECT_ID(''' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixDelete + N']'') AND type = ''P''))
    DROP PROCEDURE ' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName +  @suffixDelete + N']
'
INSERT INTO @scripts(script) VALUES(@sql)
END

SET @sql = N'-- =======================================================
-- Author:      ' + QUOTENAME(SUSER_SNAME()) + N'
-- Create date: ' + CONVERT(nvarchar(10), GETDATE(), 111) + N'
-- Description: Deletes recors from table ' + QUOTENAME(@schemaName) + '.' + QUOTENAME(@tableName) + N'
-- =======================================================
CREATE PROCEDURE ' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixDelete + N']
' + @deleteParams + N'
AS
BEGIN
    SET NOCOUNT ON;

    DELETE FROM ' + QUOTENAME(@schemaName) + N'.' + QUOTENAME(@tableName) + N'
    WHERE
' + @updateDeleteCondition + N'
END
';
INSERT INTO @scripts(script) VALUES(@sql)

--INSERT PROCEDURE
IF (@dropExistingProcedures = 1)
BEGIN
SET @sql = N'--Drop existing INSERT CRUD Procedure
IF (EXISTS (SELECT * FROM sys.objects WHERE object_id = OBJECT_ID(''' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixInsert + N']'') AND type = ''P''))
    DROP PROCEDURE ' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixInsert + N']
'
INSERT INTO @scripts(script) VALUES(@sql)
END

SET @sql = N'-- =======================================================
-- Author:      ' + QUOTENAME(SUSER_SNAME()) + N'
-- Create date: ' + CONVERT(nvarchar(10), GETDATE(), 111) + N'
-- Description: Deletes recors from table ' + QUOTENAME(@schemaName) + '.' + QUOTENAME(@tableName) + N'
-- =======================================================
CREATE PROCEDURE ' + QUOTENAME(@schemaName) + N'.[' + @procPrefix + @tableName + @suffixInsert + N']
' + @insertParams + N'
AS
BEGIN
    SET NOCOUNT ON;

    INSERT INTO ' + QUOTENAME(@schemaName) + N'.' + QUOTENAME(@tableName) + N' (
' + @insertColumns + N'
    )' + CASE WHEN @outputIndentityCalcFields = 1 AND @insertOutputCols <> N'' AND @insertOutputCols IS NOT NULL THEN N'
    OUTPUT
' + @insertOutputCols
    ELSE N'' END + N'
    SELECT
' + @insertParamNames + N'
END
';
INSERT INTO @scripts(script) VALUES(@sql)

DECLARE cr CURSOR FAST_FORWARD FOR
SELECT script FROM @scripts ORDER BY id

--if EXECUTION mode contains 2 we should output the code using SELECT
--Script generate using the SELECT can be saved by right lick on the result and
--select Save Result AS and storing it as CSV
IF ((@executionMode & 2) = 2 OR (@isTooLongForPrint = 1 AND (@executionMode & 1) = 1))
BEGIN
    SELECT script + N'GO' FROM @scripts
END

SET @isTooLongForPrint = ISNULL((SELECT 1 FROM @scripts WHERE LEN(script) > 4000), 0)

--if Execution mode contains 1 we should PRINT the statements
IF ((@executionMode & 1) = 1 AND @isTooLongForPrint = 0)
BEGIN
    OPEN cr
    FETCH NEXT FROM cr INTO @sql
    WHILE (@@FETCH_STATUS = 0)
    BEGIN
        PRINT @sql
        PRINT 'GO'
        FETCH NEXT FROM cr INTO @sql
    END
    CLOSE cr
END

--Execute the statement if it should be executed
IF (( @executionMode & 4 ) = 4 OR ( @executionMode & 8 ) = 8 )
BEGIN

    OPEN cr

    BEGIN TRY
        BEGIN TRANSACTION

        FETCH NEXT FROM cr INTO @sql
        WHILE (@@FETCH_STATUS = 0)
        BEGIN
            EXEC (@sql)
            FETCH NEXT FROM cr INTO @sql
        END

        IF ((@executionMode & 4) = 4)
        BEGIN
            IF (@@TRANCOUNT > 0)
                COMMIT TRANSACTION
        END
        ELSE
        BEGIN
            IF (@@TRANCOUNT > 0)
                ROLLBACK TRANSACTION
        END
    END TRY
    BEGIN CATCH
        IF (@@TRANCOUNT > 0)
            ROLLBACK TRANSACTION
    END CATCH
END

--if cursor is open, close it
IF (cursor_status('global', 'cr') = 1)
    CLOSE cr

DEALLOCATE cr
END
GO

EXECUTE sp_ms_marksystemobject 'dbo.sp_makeCRUD'
Go

The each of the SQL statement in the procedure is first stored in a table variable called @scripts for later printing and/or execution. At the end of the procedure the code is printed using a PRINT statement or using a SELECT statement which is automatically used in case the code for some CRUD procedure is longer than 4000 characters and therefore not possible to PRINT.

If Execute and Commit or Execute And Rollback was selected then the code for the CRUD procedures is also executed. The Execute and Rollback is useful for testing, that the code for the procedures is correct and working.

Procedure is created in the [master] database so it is accessible from all databases and we do not need to create it in every database.

To be fully functional, it is necessary to mark the procedure as system procedure using below command.

EXECUTE sp_ms_marksystemobject 'dbo.sp_makeCRUD'

Marking the procedure as system object is necessary as if we not mark the object, then the procedure will run in context of the database in which it was created – in this case [system] and will fail as there are not the tables for which we want to generate the CRUD procedures.

Once the procedure is marked as system object, then it executes in the context of the current database, even it is located in the [master] database.

After we create  the proc, we can test it on a small example:

USE [tempdb]
GO
CREATE TABLE dbo.TestTable (
    ID int NOT NULL IDENTITY(1,1) PRIMARY KEY,
    Name varchar(10),
    Price money,
    Quantity decimal(5,2),
    TotalPrice AS (Price * Quantity)
)
GO
sp_makeCRUD 'dbo.TestTable'

This will produce below code for the CRUD procedures

USE [tempdb]
GO
--Drop existing SELECT CRUD Procedure
IF (EXISTS (SELECT * FROM sys.objects WHERE object_id = OBJECT_ID('[dbo].[usp_CRUD_TestTable_S]') AND type = 'P'))
    DROP PROCEDURE [dbo].[usp_CRUD_TestTable_S]
GO
-- =======================================================
-- Author:      [PAVEL-PCPavel]
-- Create date: 2011/02/10
-- Description: Selects records from table [dbo].[TestTable]
-- =======================================================
CREATE PROCEDURE [dbo].[usp_CRUD_TestTable_S]
    @ID [int] = NULL
AS
BEGIN
    SET NOCOUNT ON;

    IF (@ID IS NULL)
    BEGIN
        SELECT
             [ID]
            ,[Name]
            ,[Price]
            ,[Quantity]
            ,[TotalPrice]
        FROM [dbo].[TestTable]
    END
    ELSE
    BEGIN
        SELECT
             [ID]
            ,[Name]
            ,[Price]
            ,[Quantity]
            ,[TotalPrice]
        FROM [dbo].[TestTable]
        WHERE
            (@ID IS NULL OR [ID] = @ID)
    END
END
GO
--Drop existing UPDATE CRUD Procedure
IF (EXISTS (SELECT * FROM sys.objects WHERE object_id = OBJECT_ID('[dbo].[usp_CRUD_TestTable_U]') AND type = 'P'))
    DROP PROCEDURE [dbo].[usp_CRUD_TestTable_U]
GO
-- =======================================================
-- Author:      [PAVEL-PCPavel]
-- Create date: 2011/02/10
-- Description: Updates record in table [dbo].[TestTable]
-- =======================================================
CREATE PROCEDURE [dbo].[usp_CRUD_TestTable_U]
    @ID [int],
    @Name [varchar](10),
    @Price [money],
    @Quantity [decimal](5, 2)
AS
BEGIN
    SET NOCOUNT ON;

    UPDATE [dbo].[TestTable] SET
         [Name] = @Name
        ,[Price] = @Price
        ,[Quantity] = @Quantity
    OUTPUT
         inserted.[TotalPrice]
    WHERE
        [ID] = @ID
END
GO
--Drop existing DELETE CRUD Procedure
IF (EXISTS (SELECT * FROM sys.objects WHERE object_id = OBJECT_ID('[dbo].[usp_CRUD_TestTable_D]') AND type = 'P'))
    DROP PROCEDURE [dbo].[usp_CRUD_TestTable_D]
GO
-- =======================================================
-- Author:      [PAVEL-PCPavel]
-- Create date: 2011/02/10
-- Description: Deletes recors from table [dbo].[TestTable]
-- =======================================================
CREATE PROCEDURE [dbo].[usp_CRUD_TestTable_D]
    @ID [int]
AS
BEGIN
    SET NOCOUNT ON;

    DELETE FROM [dbo].[TestTable]
    WHERE
        [ID] = @ID
END
GO
--Drop existing INSERT CRUD Procedure
IF (EXISTS (SELECT * FROM sys.objects WHERE object_id = OBJECT_ID('[dbo].[usp_CRUD_TestTable_I]') AND type = 'P'))
    DROP PROCEDURE [dbo].[usp_CRUD_TestTable_I]
GO
-- =======================================================
-- Author:      [PAVEL-PCPavel]
-- Create date: 2011/02/10
-- Description: Deletes recors from table [dbo].[TestTable]
-- =======================================================
CREATE PROCEDURE [dbo].[usp_CRUD_TestTable_I]
    @Name [varchar](10),
    @Price [money],
    @Quantity [decimal](5, 2)
AS
BEGIN
    SET NOCOUNT ON;

    INSERT INTO [dbo].[TestTable] (
         [Name]
        ,[Price]
        ,[Quantity]
    )
    OUTPUT
         inserted.[ID]
        ,inserted.[TotalPrice]
    SELECT
         @Name
        ,@Price
        ,@Quantity
END
GO

Selecting random records from a table

Some time you may come to a situation, when you have a table and need to get only a few random records from it. You can come with a question how to achieve this on SQL Server.

You may come with incorporating the RAND() function, but as I mentioned in my previous post Random numbers in query, the RAND() function is a constant function executed once per whole query and does not it’s work.

One of the solution could be using the TABLESAMPLE clause. All the samples here use the AdventureWorks2008R2 sample database.

SELECT
    *
FROM Sales.SalesOrderDetail
TABLESAMPLE (100 ROWS);

As this for some tables could work, probably it will not give you exact results you probably expect as the current implementation of the TABLESAMPLE clause build for purpose of statistics retrieving.

Selecting random rows using NEWID()

As working workaround for the purpose of random records selection we can use again the NEWID() function mentioned in my previous post. Each call to the function creates new unique identifier. There are several possibilities to return random rows using the function.

  1. Select an approximate percentage sample of random rows
  2. Select exact number of random rows
  3. Select an exact percentage sample of random rows
  4. Select random number of random rows

Selecting approximate percentage sample of random rows

To select an approximate percentage sample of random rows from a table you can you a below query. The query will select around 10 % of records from a table.

SELECT
    *
FROM Sales.SalesOrderDetail
WHERE 0.1 >= CAST(CHECKSUM(NEWID(), SalesOrderID) & 0x7fffffff AS float)
    / CAST (0x7fffffff AS int)

Each execution of the above query returns a different count of records, which will be close to the 10 percent of total records in the table.

To select a different percentage simply change the 0.1 to and appropriate percentage. In the condition there is added a SalesOrderID field in the calculation to force generation of the NEWID() for each row, otherwise the NEWID() would be generated only once as a constant in this query. The 0x7fffffff represents maximum positive integer value, so when using it in bit AND operation it limits the original number to that value.

The above query produces following plan:

Approximate percentage sample of random rows query plan

And trace from the profiler:

Approximate percentage sample of random rows profiler trace

The table Sales.SalesOrderDetail has 121317 rows and from the profiler results we can see, that the query returned exactly 10 % of records (without 1.7). With multiple runs the row count produced will be different, but very close to 10 %.

Selecting exact number of random rows

Selecting exact number of random rows is very easy, as it is only necessary to sort the query by the NEWID() result and limit the number of returned rows. For returning 100 random rows it’s possible to use below query:

SELECT TOP 100
    *
FROM Sales.SalesOrderDetail
ORDER BY NEWID()

In this example it is not necessary to include any random number generation and checksum as the NEWID() is in the ORDER BY clause and therefore it will be evaluated once for each row so the SQL Server can sort the record on it’s value.

Here is a plan for the query:

Exact number of random rows Query Plan

And trace from profiler:

Exact number of random rows Profiler Trace

As we can see, even the query looks much simpler than the previous for approximate percentage, this query produces much more complicated parallel plan and from the profiler we can see, that even returning les rows, it produces more reads and has much higher CPU cost. This is caused by the ORDER BY operator as the database engine has to sort all the records prior returning the TOP 100 rows. The duration of the first query is longer, but this is caused by returning 12 times more rows to client.

On small tables this doesn’t matter, but on large one it can has high impact. To solve the issue, we can use the approximate count query and limit the records returned by this query. Only we need to choose appropriate count records in the WHERE clause. If we know, that in the table is more than 120 000 records, we can first limit the results to about 0.15 % so we will be sure, the base query returns more than 100 rows and then simply limit them to 100.

SELECT TOP 100
    *
FROM Sales.SalesOrderDetail
WHERE 0.0015 >= CAST(CHECKSUM(NEWID(), SalesOrderID) & 0x7fffffff AS float)
    / CAST (0x7fffffff AS int)

This query produces below plan and trace from profiler.

Query Plan for Exact number of random rows with random generator in where condition

Profiler Trace for Exact number of random rows with random generator in where condition

As we can see, the query plan is again much simpler and the Reads count is more than half less then previous and the CPU cost is much lower and duration is a little bit lower, but generally equal because of returning rows to client.

Selecting exact percentage sample of random rows

To select an exact percentage sample of random rows it’s very simple and consist of simple modification of the TOP clause to a percentage value. So to select 10 percent of random records we can use below query.

SELECT TOP 10 PERCENT
    *
FROM Sales.SalesOrderDetail
ORDER BY NEWID()

Query produces below and again more complex plan then the solution with WHERE clause. It’s even more complicated than the one for the TOP without PERCENT as a table spool operator is added to the plan.

Query Plan for exact percentage sample of random rows

Profiler Trace for exact percentage sample of random rows

From the profiles we again see, tan it produces enormous amount of reads comparing the to the approximate percentage sample even the amount of returned records is similar. The duration and CPU cost is incomparable and even writes are produced because of the writes to Table Spool.

To optimize this, we cannot use the approximate percentage count query and limit it by percent, as the TOP 10 PERCENT clause will return only 10 percent of records from the one limited by the WHERE clause.

We can optimize the reads, execution time and resources cost by below query.

SELECT TOP ((SELECT COUNT(*) FROM Sales.SalesOrderDetail) / 10)
    *
FROM Sales.SalesOrderDetail
WHERE 0.11 >= CAST(CHECKSUM(NEWID(), SalesOrderID) & 0x7fffffff AS float)
    / CAST (0x7fffffff AS int)

The (SELECT COUNT(*) FROM Sales.SalesOrderDetail) / 10 query in TOP clause calculates 10 percent of records and whole query produces below plan and profiler trace.

Query Plan for exact percentage sample of random rows with random generator in WHERE clause

Profiler Trace for exact percentage sample of random rows with random generator in WHERE clause

Even the plan may look more complex than the previous one, from the profiler trace we can see, that for the same Row Count this plan produces 256 time less reads, no writes and 3 time lower duration and 6.5 time less CPU cost.

Selecting random number of random records

To select a random number of random records we can again use the above query and slightly modify the top clause. This modification consist of adding a random generator into the TOP clause. To select random number of records (or percent) in particular interval – in this example 10-20 records or 10 – 20 percent a below queries can be used:

--Select 10 - 20 random records
SELECT TOP (ABS(CHECKSUM(NEWID())) % 10 + 10)
    *
FROM Sales.SalesOrderDetail
ORDER BY NEWID()

--Select 10 - 20 random records
SELECT TOP (ABS(CHECKSUM(NEWID())) % 10 + 10)
    *
FROM Sales.SalesOrderDetail
WHERE 0.0022 >= CAST(CHECKSUM(NEWID(), SalesOrderID) & 0x7fffffff AS float)
    / CAST (0x7fffffff AS int)

Profiler Trace for Random number of random records

The plans for the queries are the same as the plan mentioned above and from the profiler trace we can again see, the incomparable lower costs of the second query compared to the first one.

--Select 10 - 20 % of random records
SELECT TOP (ABS(CHECKSUM(NEWID())) % 10 + 10) PERCENT
    *
FROM Sales.SalesOrderDetail
ORDER BY NEWID()

--Select 10 - 20 % of random records
SELECT TOP ((SELECT COUNT(*) FROM Sales.SalesOrderDetail) * (ABS(CHECKSUM(NEWID())) % 10 + 10) / 100)
    *
FROM Sales.SalesOrderDetail
WHERE 0.21 >= CAST(CHECKSUM(NEWID(), SalesOrderID) & 0x7fffffff AS float)
    / CAST (0x7fffffff AS int)

Profiler Trace for Random percentage of random records

Again the plan are the same as the plan for each version showed above and again from the profiler trace we can again see, that the performance of the second query is incomparable better, than the first one.

Complete comparison

To make a complete comparison of performance of all the queries mentioned in this article we can use below query batch. All the queries are written as sub queries of SELECT COUNT(*) to avoid wrong duration calculation which is affected by transferring the records from server to client.

--Approximate 10 percent =======================
SELECT COUNT(*) FROM (
    SELECT
        *
    FROM Sales.SalesOrderDetail
    WHERE 0.1 >= CAST(CHECKSUM(NEWID(), SalesOrderID) & 0x7fffffff AS float)
        / CAST (0x7fffffff AS int)
) q
GO
--TOP 100, ORDER BY =============================
SELECT COUNT(*) FROM (
    SELECT TOP 100
        *
    FROM Sales.SalesOrderDetail
    ORDER BY NEWID()
) q
GO
--TOP 100, Approximate =============================
SELECT COUNT(*) FROM (
    SELECT TOP 100
        *
    FROM Sales.SalesOrderDetail
    WHERE 0.0015 >= CAST(CHECKSUM(NEWID(), SalesOrderID) & 0x7fffffff AS float)
        / CAST (0x7fffffff AS int)
) q
GO
--TOP 10 PERCENT, ORDER BY =============================
SELECT COUNT(*) FROM (
    SELECT TOP 10 PERCENT
        *
    FROM Sales.SalesOrderDetail
    ORDER BY NEWID()
) q
GO
--TOP 10 PERCENT, Approximate =============================
SELECT COUNT(*) FROM (
    SELECT TOP ((SELECT COUNT(*) FROM Sales.SalesOrderDetail) / 10)
        *
    FROM Sales.SalesOrderDetail
    WHERE 0.11 >= CAST(CHECKSUM(NEWID(), SalesOrderID) & 0x7fffffff AS float)
        / CAST (0x7fffffff AS int)
) q
GO
--Random 10 - 20 Records, ORDER BY  =============================
SELECT COUNT(*) FROM (
    SELECT TOP (ABS(CHECKSUM(NEWID())) % 10 + 10)
        *
    FROM Sales.SalesOrderDetail
    ORDER BY NEWID()
) q
GO
--Random 10 - 20 Records, Approximate =============================
SELECT COUNT(*) FROM (
    SELECT TOP (ABS(CHECKSUM(NEWID())) % 10 + 10)
        *
    FROM Sales.SalesOrderDetail
    WHERE 0.0022 >= CAST(CHECKSUM(NEWID(), SalesOrderID) & 0x7fffffff AS float)
        / CAST (0x7fffffff AS int)
) q
GO
--Random 10 - 20 PERCENT, ORDER BY =============================
SELECT COUNT(*) FROM (
    SELECT TOP (ABS(CHECKSUM(NEWID())) % 10 + 10) PERCENT
        *
    FROM Sales.SalesOrderDetail
    ORDER BY NEWID()
) q
GO
--Random 10 - 20 PERCENT, Approximate =============================
SELECT COUNT(*) FROM (
    SELECT TOP ((SELECT COUNT(*) FROM Sales.SalesOrderDetail) * (ABS(CHECKSUM(NEWID())) % 10 + 10) / 100)
        *
    FROM Sales.SalesOrderDetail
    WHERE 0.21 >= CAST(CHECKSUM(NEWID(), SalesOrderID) & 0x7fffffff AS float)
        / CAST (0x7fffffff AS int)
) q
GO

And profiler output for above queries.

Queries comparison profiler trace output

Conclusion

As we can see from the queries, their query plans and profiler traces, we have several possibilities to select random records from table. Some possibilities have a very simpler query, but produces more complex plan and have a higher cost and can be suitable for relatively small tables.

Other versions producing the same results are more complex to write the query itself, but finally the query produces a much simpler plan and have much better performance comparing to the simple looking one. Such queries are then suitable even fro very large tables to produce results in acceptable time with low performance impact on the server.

Random numbers in query

Some times you may want to select rows from some table and in each row you would like to have some random number generated. You may want to try the RAND() function. However, it will generate a random number, all the returned rows will have the same random number and this is mostly not what you intended.

SELECT TOP 10
    RAND()
FROM sys.all_columns

Running the above query you will receive.

----------------------
0,173895240378828
0,173895240378828
0,173895240378828
0,173895240378828
0,173895240378828
0,173895240378828
0,173895240378828
0,173895240378828
0,173895240378828
0,173895240378828

(10 row(s) affected)

This is caused because the RAND() function is a constant function and the constant function is executed once on the query start, and then the value is used everywhere in the query. There are more functions in SQL Server, that behave as Constant Expressions and which are executed once per the whole Query e.g. the GETDATE() function.

Whether the function is a executed as constant expression or whether it is executed once per row, you can find from the XML plan for the query. If we take the a look on the XML plan for the above query we will see:

<?xml version="1.0" encoding="utf-16"?>
<ShowPlanXML xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:xsd="http://www.w3.org/2001/XMLSchema" Version="1.1" Build="10.50.1600.1" xmlns="http://schemas.microsoft.com/sqlserver/2004/07/showplan">
  <BatchSequence>
    <Batch>
      <Statements>
        <StmtSimple StatementCompId="1" StatementEstRows="10" StatementId="1" StatementOptmLevel="FULL" StatementOptmEarlyAbortReason="GoodEnoughPlanFound" StatementSubTreeCost="0.00346253" StatementText="SELECT TOP 10
    RAND()
FROM sys.all_columns" StatementType="SELECT" QueryHash="0x479AE6BF06344217" QueryPlanHash="0x1960EA8D4F47E514">
          <StatementSetOptions ANSI_NULLS="true" ANSI_PADDING="true" ANSI_WARNINGS="true" ARITHABORT="true" CONCAT_NULL_YIELDS_NULL="true" NUMERIC_ROUNDABORT="false" QUOTED_IDENTIFIER="true" />
          <QueryPlan CachedPlanSize="32" CompileTime="3" CompileCPU="3" CompileMemory="544">
            <RelOp AvgRowSize="15" EstimateCPU="1E-06" EstimateIO="0" EstimateRebinds="0" EstimateRewinds="0" EstimateRows="10" LogicalOp="Compute Scalar" NodeId="0" Parallel="false" PhysicalOp="Compute Scalar" EstimatedTotalSubtreeCost="0.00346253">
              <OutputList>
                <ColumnReference Column="Expr1063" />
              </OutputList>
              <ComputeScalar>
                <DefinedValues>
                  <DefinedValue>
                    <ColumnReference Column="Expr1063" />
                    <ScalarOperator ScalarString="rand()">
                      <Identifier>
                        <ColumnReference Column="ConstExpr1065">
                          <ScalarOperator>
                            <Intrinsic FunctionName="rand">
                              <ScalarOperator>
                                <Const ConstValue="" />
                              </ScalarOperator>
                            </Intrinsic>
                          </ScalarOperator>
                        </ColumnReference>
                      </Identifier>
                    </ScalarOperator>
                  </DefinedValue>
                </DefinedValues>
                <RelOp AvgRowSize="9" EstimateCPU="1E-06" EstimateIO="0" EstimateRebinds="0" EstimateRewinds="0" EstimateRows="10" LogicalOp="Top" NodeId="1" Parallel="false" PhysicalOp="Top" EstimatedTotalSubtreeCost="0.00346153">
                  <OutputList />
                  <Top RowCount="false" IsPercent="false" WithTies="false">
                    <TopExpression>
                      <ScalarOperator ScalarString="(10)">
                        <Const ConstValue="(10)" />
                      </ScalarOperator>
                    </TopExpression>
                    <RelOp AvgRowSize="9" EstimateCPU="0.000515516" EstimateIO="0" EstimateRebinds="0" EstimateRewinds="0" EstimateRows="10" LogicalOp="Concatenation" NodeId="2" Parallel="false" PhysicalOp="Concatenation" EstimatedTotalSubtreeCost="0.00346053">
                      <OutputList />
                      <Concat>
                        <DefinedValues />
                        <RelOp AvgRowSize="9" EstimateCPU="0.00083584" EstimateIO="0" EstimateRebinds="0" EstimateRewinds="0" EstimateRows="10" LogicalOp="Filter" NodeId="3" Parallel="false" PhysicalOp="Filter" EstimatedTotalSubtreeCost="0.00337579">
                          <OutputList />
                          <Filter StartupExpression="false">
                            <RelOp AvgRowSize="13" EstimateCPU="0.0008753" EstimateIO="0.0068287" EstimateRebinds="0" EstimateRewinds="0" EstimateRows="10" LogicalOp="Index Scan" NodeId="4" Parallel="false" PhysicalOp="Index Scan" EstimatedTotalSubtreeCost="0.00335999" TableCardinality="653">
                              <OutputList>
                                <ColumnReference Database="[TestDB]" Schema="[sys]" Table="[syscolpars]" Column="id" />
                              </OutputList>
                              <IndexScan Ordered="false" ForcedIndex="false" ForceSeek="false" NoExpandHint="false">
                                <DefinedValues>
                                  <DefinedValue>
                                    <ColumnReference Database="[TestDB]" Schema="[sys]" Table="[syscolpars]" Column="id" />
                                  </DefinedValue>
                                </DefinedValues>
                                <Object Database="[TestDB]" Schema="[sys]" Table="[syscolpars]" Index="[nc]" IndexKind="NonClustered" />
                                <Predicate>
                                  <ScalarOperator ScalarString="[TestDB].[sys].[syscolpars].[number]=(0)">
                                    <Compare CompareOp="EQ">
                                      <ScalarOperator>
                                        <Identifier>
                                          <ColumnReference Database="[TestDB]" Schema="[sys]" Table="[syscolpars]" Column="number" />
                                        </Identifier>
                                      </ScalarOperator>
                                      <ScalarOperator>
                                        <Const ConstValue="(0)" />
                                      </ScalarOperator>
                                    </Compare>
                                  </ScalarOperator>
                                </Predicate>
                              </IndexScan>
                            </RelOp>
                            <Predicate>
                              <ScalarOperator ScalarString="has_access('CO',[TestDB].[sys].[syscolpars].[id])=(1)">
                                <Compare CompareOp="EQ">
                                  <ScalarOperator>
                                    <Intrinsic FunctionName="has_access">
                                      <ScalarOperator>
                                        <Const ConstValue="'CO'" />
                                      </ScalarOperator>
                                      <ScalarOperator>
                                        <Identifier>
                                          <ColumnReference Database="[TestDB]" Schema="[sys]" Table="[syscolpars]" Column="id" />
                                        </Identifier>
                                      </ScalarOperator>
                                      <ScalarOperator>
                                        <Const ConstValue="" />
                                      </ScalarOperator>
                                      <ScalarOperator>
                                        <Const ConstValue="" />
                                      </ScalarOperator>
                                    </Intrinsic>
                                  </ScalarOperator>
                                  <ScalarOperator>
                                    <Const ConstValue="(1)" />
                                  </ScalarOperator>
                                </Compare>
                              </ScalarOperator>
                            </Predicate>
                          </Filter>
                        </RelOp>
                        <RelOp AvgRowSize="9" EstimateCPU="0.0132712" EstimateIO="0.0749769" EstimateRebinds="0" EstimateRewinds="0" EstimateRows="1" LogicalOp="Index Scan" NodeId="6" Parallel="false" PhysicalOp="Index Scan" EstimatedTotalSubtreeCost="0.00329434" TableCardinality="11922">
                          <OutputList />
                          <IndexScan Ordered="false" ForcedIndex="false" ForceSeek="false" NoExpandHint="false">
                            <DefinedValues />
                            <Object Database="[mssqlsystemresource]" Schema="[sys]" Table="[syscolrdb]" Index="[ncl]" IndexKind="NonClustered" />
                            <Predicate>
                              <ScalarOperator ScalarString="[mssqlsystemresource].[sys].[syscolrdb].[number]=(0)">
                                <Compare CompareOp="EQ">
                                  <ScalarOperator>
                                    <Identifier>
                                      <ColumnReference Database="[mssqlsystemresource]" Schema="[sys]" Table="[syscolrdb]" Column="number" />
                                    </Identifier>
                                  </ScalarOperator>
                                  <ScalarOperator>
                                    <Const ConstValue="(0)" />
                                  </ScalarOperator>
                                </Compare>
                              </ScalarOperator>
                            </Predicate>
                          </IndexScan>
                        </RelOp>
                      </Concat>
                    </RelOp>
                  </Top>
                </RelOp>
              </ComputeScalar>
            </RelOp>
          </QueryPlan>
        </StmtSimple>
      </Statements>
    </Batch>
  </BatchSequence>
</ShowPlanXML>

On the line 19 or the Query you can see ConstExpr1065 under the node of <ScalarOperator ScalarString="rand()">. Each function which is in the XML plan expressed in the ColumnReference as ConstExpr is executed as constant function once per whole query.

Workaround for RAND function

As a workaround for generating the random numbers in a query, it is possible to use the NEWID() function. Although it the return value of the function is uniqueidentifier, every call to the function return a new unique value, which we can use a CHECKSUM() function over it which calculates checksum of an expression the checksum is an integer value. Because the value can be negative or positive it is necessary to use ABS() over it to receive consistent values.

So finally we can write following query:

SELECT TOP 10
    ABS(CHECKSUM(NEWID())) AS Random,
    ABS(CHECKSUM(NEWID())) % 100 AS Random_0_100,
    CAST(CHECKSUM(NEWID()) & 0x7fffffff AS float) / CAST(0x7fffffff as int)  AS RandomFloatValue
FROM sys.all_objects

And the result will be similar to the one below where each value is unique random number.

Random      Random_0_100 RandomFloatValue
----------- ------------ ----------------------
1060745673  73           0,290147927724825
1053300815  99           0,835112006792385
1233927720  13           0,551734537608798
1059863691  70           0,316186188401741
495435569   98           0,770220997636309
1364620416  82           0,404617617095177
783618590   58           0,161057420615599
1176654027  15           0,522251577825403
1871862272  0            0,295878297321442
1870125345  10           0,0176546154625968

(10 row(s) affected)

SQL Script Manager by RedGate

On December 16. 2010 RedGate released a free tool for DBAs for managing and and running T-SQL or IronPython scripts. You can download the script manager directly from RedGate SQL Script Manager site.

SQL Script Manager

The script manager allows you to manage collects scripts, and simplify their execution using Presets. Scripts are organized by Tags and Authors.

Script manager comes pre-bundled with 25 administration scripts and other scripts can be downloaded from SqlCentral.com scripts repository.

User can even create it’s own scripts. The scripts are encapsulated inside the .rgtool file, which is an XML file which structure is described on the RedGate support pages for the SQL Script Manager.

However it is interesting tool for collecting and managing scripts, I think, it brings nothing special what cannot be handled by the Templates and Templates Manager integrated in Management Studio (if talking about T-SQL Scripts). What more, SQL Management Studio Denali brings a new Code Snippets known from C# and VB .NET development in Visual Studio, which brings another power to the SSMS and from my point of view, writing the .rgtool is more complicated than writing a T-SQL template. On the other site it could be a useful tool for beginners DBAs.
